34
Installation EAGLE20/30
Release
06
04/2014
2.6 Operating the device
Note: Relevant for North America:
The torque for tightening the working voltage terminal block on the device is
4.5 lb-in (0.51 Nm).
The torque for tightening the signal contact and input terminal block on the
device is 3 lb-in (0.34 Nm).
Use screws to secure the connecters to the device.
Enable the working voltage.
2.7 Connecting data cables
2.7.1 10/100 Mbit/s twisted pair port
Note: In general, adhere to the following recommendations for data cable
connections in environments with high electrical interference levels:
Keep the length of the data cables as short as possible.
Use optical data cables for the data transmission between the buildings.
When using copper cables, provide a sufficient gap between the power
supply cables and the data cables, when laid over a long distance. Ideally,
install the cables in separate cable channels.
Use shielded cables.
Connect the data cable according to your requirements.
2.7.2 100/1000 Mbit/s twisted pair port (optional)
Note: Applies solely for EAGLE20/30 devices with HiSecOS from software
version 01.2.00
WARNING
ELECTRIC SHOCK
Connect solely an working voltage that corresponds to the type plate of your
device.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.
