Ring/Network coupling
Redundanz L2P
Release
5.0
04/09
5.2
Preparing a Ring/Network coupling
61
Device Partner coupling port Coupling port
RS2-./. Not possible Not possible
RS2-16M All ports (default setting: port 2) All ports (default setting: port 1)
RS20, RS30,
RS40
All ports (default setting: port 1.3) All ports (default setting: port 1.4)
OCTOPUS All ports (default setting: port 1.3) All ports (default setting: port 1.4)
MICE All ports (default setting: port 1.3) All ports (default setting: port 1.4)
Power MICE All ports (default setting: port 1.3) All ports (default setting: port 1.4)
MS20 All ports (default setting: port 1.3) All ports (default setting: port 1.4)
MS30 All ports (default setting: port 2.3) All ports (default setting: port 2.4)
RSR20/30 All ports (default setting: port 1.3) All ports (default setting: port 1.4)
MACH 100 All ports (default setting: port 2.3) All ports (default setting: port 2.4)
MACH 1000 All ports (default setting: port 1.3) All ports (default setting: port 1.4)
MACH 3000 All ports All ports
MACH 4000 All ports (default setting: port 1.3) All ports (default setting: port 1.4)
Table 9: Port assignment for one-Switch coupling
Note: Configure the partner coupling port and the HIPER-Ring ports on
different ports.
Select the coupling port (see fig. 25), (see table 9).
With “Coupling port” you specify at which port you are connecting
the redundant line.
Note: Configure the coupling port and the redundancy ring ports on
different ports.
Activate the function in the “Operation” frame (see fig. 31).
You now connect the redundant line.
The displays in the “Select port” frame mean (see fig. 25):
– “Port mode”: The port is either active or in stand-by mode.
– “Port state”: The port is either connected or not connected.
The displays in the “Information” frame mean (see fig. 25):
– “Redundancy existing”: One of the lines affected can fail, as a
redundant line will then take over the function of the failed line.
– “Configuration failure”: The function is incomplete or incorrectly
configured.
