Installation MSP30/32/40/42 and MSM20/22/24/40/42/46/50
Release
12
06/2018
Note: For the pin assignment see table 23 on page 36.
8.4 24 V DC auxiliary voltage (AUX)
Note: For the pin assignment see table 23 on page 36.
8.5 External PoE power supply (MSM46)
Note: For the pin assignment see “MSM22, MSM42 and MSM46 media
modules” on page 45.
Digital output acc. to IEC 61131-2 (current-consuming) Yes
Connection type 12-pin terminal block
Output voltage range +24 V DC ... +27 V DC
Maximum output power 3.0 W
Short-circuit protection yes (electronically)
Under-voltage deactivation Yes
Connection type 2-pin terminal block
Rated voltage Device variants with PoE: 48 V DC
Device variants with PoE Plus: 54 V DC
Voltage range incl. maximum
tolerances
Device variants with PoE: 45 V DC ... 57 V DC
Device variants with PoE Plus: 51 V DC ... 57 V DC
Max. PoE power 62 W
Connection type 3-pin terminal block
Back-up fuse Nominal rating: 6.3 A
Characteristic: slow blow
Peak inrush current < 5 A
