Redundant coupling
26
3.2
Configuring the redundant coupling
Redundancy L2E
Release
4.1
03/08
Note: Some devices have a DIP switch, with which you can choose between
the software configuration and the DIP configuration. If the software con-
figuration is set, the other DIP switches have no effect.
Note: The choice of configuration primarily depends on the topological
conditions and the desired level of security (see table 4).
Note: For redundancy security reasons, a combination of Rapid Spanning
Tree and Ring/Network Coupling is not possible.
Note: Depending on the STAND-BY DIP switch position, the dialog dis-
plays those configurations that are not possible in gray. If you want to
select one of these grayed-out configurations, you put the STAND-BY
DIP switch on the Switch into the other position.
Note: One-Switch coupling: The redundancy function is assigned to the
Switch via the “STAND-BY” setting in the DIP switch, or via the
Management.
Note: Two-Switch coupling: The redundancy function is assigned to the
Switch in the redundant line via the “STAND-BY” setting in the DIP
switch, or via the Management.
