Configuring the redundant coupling
29
Select the coupling port (see fig. 9), (see table 8).
With “Coupling port” you specify at which port you are connecting
the redundant line.
Switch Coupling port
RS2-../.. Not possible
RS2-16M Adjustable for all ports (default setting: port 1)
RS20 Adjustable for all ports (default setting: port 1.4)
RS30 Adjustable for all ports (default setting: port 1.4)
RS40 Adjustable for all ports (default setting: port 1.4)
MICE Adjustable for all ports (default setting: port 1.4)
PowerMICE Adjustable for all ports (default setting: port 1.4)
MS 20 Adjustable for all ports (default setting: port 1.4)
MS 30 Adjustable for all ports (default setting: port 2.4)
RSR20/30 Adjustable for all ports (default setting: port 1.4)
MACH 1000 Adjustable for all ports (default setting: port 1.4)
MACH 3000 Adjustable for all ports
MACH 4000 Adjustable for all ports (default setting: port 1.4)
Table 8: Port assignment for one-Switch coupling
Note: Configure the coupling port and the HIPER-Ring ports on
different ports.
Activate the function in the “Operation” frame (see fig. 9).
You now connect the redundant line.
The displays in the “Select port” frame mean (see fig. 9):
– “Port mode”: The port is either active or in stand-by mode.
– “Port state”: The port is either connected or not connected.
The displays in the “Information” frame mean (see fig. 9):
– “Redundancy guaranteed”: One of the lines affected can fail, as a
redundant line will then take over the function of the failed line.
– “Configuration failure”: The function is incomplete or incorrectly
configured.
