Interference proof
Discharge of static electricity
Contact discharge EN 61000-4-2 Test level 2
Air discharge EN 61000-4-2 Test level 3
Electromagnetic fields EN 61000-4-3 Test level 3
Fast transients EN 61000-4-4 Test level 3
Surge voltage symmetrical EN 61000-4-5 Test level 2
Surge voltage asymmetrical EN 61000-4-5 Test level 3
Cable-based RF faults EN 61000-4-6 Test level 3
EMC emitted immunity
EN 55022 Class A
FCC 47 CFR Part 15 Class A
Stability
Vibration IEC 60068-2-6 Test FC, testing level in line with IEC 61131-2 E2 CDV and
Shock IEC 60068-2-27 Test Ea, testing level in line with IEC 61131-2 E2 CDV
Certifications
cUL 508 / CSA 22.2 No.142 pending
Network size
TP port 10BASE-T/100BASE-TX
Length of a twisted pair segment 100 m (328 ft) maximum
Interfaces
5 TP ports RJ45 sockets, 10/100 MBit/s
Displays
Equipment status 1 x green LED P – power, supply voltage present
Port status 5 x green LEDs DAT/STAT – data, link status
5 x yellow LEDs 10/100 – Data rate
Scope of delivery
Rail Switch SPIDER 5TX incl. terminal block for supply voltage
description and operating instructions
Order number
Rail Switch SPIDER 5TX 943 824-001
Accessories
ETHERNET manual 943 320-011
Manual
Basics i ETHERNET and TCP/IP 280 720-834
Rail Power Supply RPS 30 943 662-003
Rail Power Supply RPS 60 943 662-001
Rail Power Supply RPS 120 943 662-011
Hirschmann Electronics GmbH & Co. KG
Automation and Network Solutions
Stuttgarter Straße 45-51
D-72654 Neckartenzlingen
Germany
Tel.: ++49 / 1805 / 14-1538
Fax: ++49 / 7127 / 14-1551
E-Mail: ans-support@nt.hirschmann.de
Internet: http://www.hirschmann.com
Printed in Germany
Subject to alterations
