Installation In Horizontal Sliding Windows
NOTE:The window installation kit can be used with vertical sliding windows between 18'' and 50'' wide.
Foal seal N
(Adhesive
type-shorter)
Foal seal M
(Adhesive type)
A
E or F
9
Cut the foam seal M(adhesive type) &
N (adhesive type-shorter)to the proper
length,and attcah it to the window sash
and frame.
Cut the foam seal A(Non-adhesive type)
to the window width.Stuff the foam seal
A
between the glass and the window to
prevent air and insects from getting into
the room.
Install the Window-lock bracket with a E or F screw as
shown if you need. E screw is suitable for wood window,
F screw is suitable for metal window.
Insert the vent panel assembly,including
extension panels,if needed，into the window
opening.Extend the extension panels,if used.
To Next Page
