Bluetooth remote control module specifications
WNF171
Frequency Range: 2.400GHz~2.4835GHz
Output Power(Max.): +4.5dBm
NOTE:
The included remote control will vary depending on model, countries/regions.
Check information according to the actual remote control in the accessory bag.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
: Switch the TV on or into standby mode
2
INPUT: Select input sources
3
: Activate the microphone
4
: Media content control function buttons
5
: Enter Channels / input numbers and special
function buttons (Red/Green/Yellow/Blue)
6
/ / < / >
: Allow you to navigate the on-screen
menus and adjust the system settings to your
preference
7
OK: Confirm the selection in the on-screen menus
8
: Return to previous menu
9
: Display the Quick setup menu
10
: Enter the Home screen
11
VOL / : Adjust the volume
12
CH / : Switch channel
13
:
Mute and restore sound
14
APP: Quick access buttons to apps
MEDIA: Enter the media mode
Remote Control
