18
Specifications
Item
58"
Dimension
(W × H × D)
Without Stand
51.0 × 29.6 × 2.8 inches
(1295 × 752 × 70 mm)
With Stand
51.0 × 32.0 × 11.5 inches
(1295 × 812 × 291 mm)
Weight
Without Stand
27.6 lbs (12.5 kg)
With Stand
27.8 lbs (12.6 kg)
Active Screen Size (Diagonal)
146 cm
Screen resolution
3840 × 2160
Audio power
8W + 8W
Operating mode power density
0.015
Watts/cm²
Power consumption when turned off
N.A.
Power consumption in standby mode
0.5 W
Power consumption
Please refer to the rating label.
Power supply
Please refer to the rating label.
Receiving
systems
Analogue
PAL-D/K, B/G, I, SECAM-D/K, B/G
Digital
DVB-T/T2, DVB-C, DVB-S/S2
Wireless
LAN Module
specifications
Model
ZDGF7638GU-T
Frequency Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz 16dBm
Bluetooth
Module
specifications
Model
ZDGF7638GU-T
Frequency Range
2.4~2.4835GHz
Output Power
(Max.)
2.4~2.4835GHz,Class1,6dBm
Environmental conditions
Temperature: 41°F - 95°F (5°C - 35°C)
Humidity: 20% - 80% RH
Atmospheric pressure: 86 kPa - 106 kPa
HDMI Input
RGB / 60Hz (640×480, 800×600, 1024×768)
YUV / 60Hz (480i, 480p, 720p, 1080i, 1080p)
YUV / 50Hz (576i, 576p, 720p, 1080i, 1080p)
3840×2160 / 24Hz, 3840×2160 / 25Hz,
3840×2160 / 30Hz, 3840×2160 / 50Hz,
3840×2160 / 60Hz
