Hisense HCHM-N04X User Manual

HCHM-N08X
HCHM-N12X
Figure2.2DimensionsofSwitch Box
Unit:mm
EFGHCDBA
60
156
67
60
580
25630
20
110
198
67
352
551
260
199
86
38 543
780
24017635
34
50
244
180
60
156
42
38
Outdoor Unit Connecting Side
Indoor Unit Connecting Side
(For Suspension Bolt)
Electrical Box
Control Wiring Connection
(2 x ˜26)
Refrigerant Liquid Pipe
Connections
(8 x ˜9.52 Flare Nuts)
Refrigerant Gas
Pipe Connection
(8 x ˜15.88
Flare Nuts)
Power Supply Wiring
Connection (˜26)
Ground Terminal (M5)
(in Electrical Box)
60 x 7 = 420
Refrigerant Gas
(High/Low Pressure)
Pipe Connection
(I.D. ˜22.36)
Suspension Bracket
4 - (12 x 32) Slotted Hole
(For Suspension Bolt)
Refrigerant Gas
(Low Pressure)
Pipe Connection
(I.D. ˜28.75)
Refrigerant Liquid
Pipe Connection
(I.D. ˜12.9)
P
View from P
DCBAEFGHIJKL
60
156
60
67
82020
25630
110
198
38 78338
1020
50
180
244
42
60
156
34
35 176240 240
67
352
551
260
199
86
Outdoor Unit Connecting Side
Indoor Unit Connecting Side
(For Suspension Bolt)
Electrical Box
Control Wiring Connection
(3 x ˜26)
Refrigerant Liquid Pipe Connections
(12 x ˜9.52 Flare Nuts)
Refrigerant Gas Pipe Connection
(12 x ˜15.88 Flare Nuts)
Power Supply Wiring
Connection (˜26)
Ground Terminal (M5)
(in Electrical Box)
60 x 11 = 660
Refrigerant Gas
(High/Low Pressure)
Pipe Connection
(I.D. ˜25.6)
Suspension Bracket
4 - (12 x 32) Slotted Hole
(For Suspension Bolt)
Refrigerant Gas
(Low Pressure)
Pipe Connection
(I.D. ˜28.75)
Refrigerant Liquid
Pipe Connection
(I.D. ˜16.1)
P
View from P
Specification
Model HCHM-N12X
PowerSupply
220-240V～50Hz
220V～ 60Hz
Input(W) 33.6
Refrigerant R410A
NetWeight(kg) 36
ConnectableIndoorUnit
TotalCapacity
30.0HPorless
ConnectableIndoorUnit
TotalCapacityperBranch
6.0HPorless
(Max.16.0kW)
NumberofConnectable
IndoorUnitperBranch
1to6
Specification
Model HCHM-N08X
PowerSupply
220-240V～50Hz
220V～ 60Hz
Input(W) 22.4
Refrigerant R410A
NetWeight(kg) 25
ConnectableIndoorUnit
TotalCapacity
30.0HPorless
ConnectableIndoorUnit
TotalCapacityperBranch
6.0HPorless
(Max.16.0kW)
NumberofConnectable
IndoorUnitperBranch
1to6
2
