Hisense HRF266N6CSE User Manual

41
Control Panel
Remove the Control Panel Display
1. Unplug the refrigerator, or disconnect power.
2. Using a Phillips screwdriver, remove the three
screws fastening the hinge cover, and then
remove the hinge cover from the top of the
cabinet.
a
a Hinge cover screws
3. Disconnect the wire harnesses.
4. Using a Phillips screwdriver, remove the screws
from the back of the control panel.
5. Remove the terminal.
6. Remove the two screws fastening the electrical
board to the front of the electronic display.
7. Remove the electrical board.

Hisense HRF266N6CSE Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	25 cu. ft.
Refrigerator Capacity	13.9 cu. ft.
Freezer Capacity	5.5 cu. ft.
Number of Refrigerator Shelves	5 Total (4 Adjustable Half-Width; 1 Fixed Full-Width)
Number of Refrigerator Bins	4
Humidity Controlled Crispers	2 Half Crispers & 1 Full Width Pantry
Number of Freezer Shelves/Baskets	2 Drawers
Refrigerator Temperature	34° F to 47° F
(-14°C)	-
Refrigerator Special Features	LED Lighting
Freezer Special Features	Quick Freeze
Defrost System	-
Noise level	43 dB
Refrigerant	R600a
Energy Class	E
Annual Energy Consumption	628 kWh
Voltage	-
Frequency	-
Current	-

Weight and Dimensions

Depth	27 in
Height	72 1/2 in
Width	32 7/8 in
Net Weight	232.75 lbs
