Hisense HRF266N6CSE User Manual

6
Door Removal
(only if needed)
Measure the refrigerator to make sure it will fit
through the doorway. If the refrigerator cannot
pass easily through the doorway, follow the
instructions to remove the two refrigerator
compartment doors and the front panel of the
freezer drawer.
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
Reconnect ground wire before operating.
Failure to do so could result in death or electric
shock.
Tools needed
•
Phillips Screwdriver
•
4 mm Hex-key wrench
•
8 mm Socket wrench
Remove the Doors
IMPORTANT: Keep the refrigerator doors closed
until you are ready to lift them from the cabinet.
1. Unplug refrigerator or disconnect power.
2. Using a Phillips screwdriver, remove the three
screws attaching the hinge cover and control
panel to the top of the cabinet.
Fridge
Super
Cool
Energy
Saving
Freezer
°F/°C
(3s)
Ice
On/Off
Super
Freeze
a b
a Screws
b Hinge cover
3. Gently lift the hinge cover, keeping the wire
harness attached, and move the cover/wire
harness assembly behind the door hinges on
the cabinet top.
4. Disconnect the wiring harness by pressing the
release catch on the wire harness connector,
and then pulling the ends apart (left-hand
hinge only).
a
a Wiring harness
5. Using an 8 mm socket wrench, remove the
three screws fastening the top hinge to the
cabinet, and then remove the ground screw
(left-hand hinge only).
a
b
a Screws
b Ground screw
NOTE: Provide additional support for the
door while the hinge is being removed. Do not
depend on the door gasket magnets to hold
the door in place while you are working.
6. Remove the top door hinge.
IMPORTANT: For the door to close properly
in the future, DO NOT lift the door from the
bottom hinge if it is open to an angle narrower
than a 90° angle.
7. Open the door to a 90° or wider angle.
90°

Hisense HRF266N6CSE Specifications

General

Style	French Door
Color	Stainless Steel
Number of Doors	3
Total Capacity	25 cu. ft.
Refrigerator Capacity	13.9 cu. ft.
Freezer Capacity	5.5 cu. ft.
Number of Refrigerator Shelves	5 Total (4 Adjustable Half-Width; 1 Fixed Full-Width)
Number of Refrigerator Bins	4
Humidity Controlled Crispers	2 Half Crispers & 1 Full Width Pantry
Number of Freezer Shelves/Baskets	2 Drawers
Refrigerator Temperature	34° F to 47° F
(-14°C)	-
Refrigerator Special Features	LED Lighting
Freezer Special Features	Quick Freeze
Defrost System	-
Noise level	43 dB
Refrigerant	R600a
Energy Class	E
Annual Energy Consumption	628 kWh
Voltage	-
Frequency	-
Current	-

Weight and Dimensions

Depth	27 in
Height	72 1/2 in
Width	32 7/8 in
Net Weight	232.75 lbs
