6
ENGLISH
2. Plug the connected devices into the main power socket before switching on the TV.
•
TIP:
If you prefer to use Audio Return Channel, then see
Connecting an audio device to use Audio Return Channel
(ARC) on page 6
.
NOTES
• When a digital audio system is connected to the
DIGITAL AUDIO OUT
port, decrease the TV and system volume.
• 5.1 CH (channel) audio is available when the TV is connected to an external device that supports a 5.1 channel
surround sound when using Audio Return Channel (ARC) feature.
Connecting an audio device to use Audio Return Channel (ARC)
If you’d like to use the Audio Return Channel (ARC) feature to have sound sent from the TV back down an HDMI cable
to an audio device, then you will need to connect the cable to the
HDMI / ARC
port. By using this feature, you will also
be able to control the audio device with your TV remote instead of having to use multiple remotes for each device.
To connect an audio device with an HDMI cable (not provided):
1. Connect the audio device to the
HDMI / ARC
port on the TV.
2. Make sure your audio device is powered on.
3. Press the
Home
button on your remote and select the
Settings
icon, then go to
Sound
>
Speakers
.
4. Select the
ARC
option.
NOTE
• If the audio device has an Input Selector feature then set it to the proper input.
Connecting a USB device
You can connect the USB devices such as hard
drives, USB sticks and digital cameras for browsing
photos, listening music and watching recorded
movies.
1. Connect a USB device into the
USB
port.
2. Select the Media type on the
Media
screen. For
more information, see
Media on page 28
EXTERNAL DEVICES
Powerless
Bass Speaker
Speaker
Digital Sound Bar
Audio Amplifier
DIGITAL
AUDIO OUT
TV PORTS
Audio Cable
White (L)White (L)
Red (R)
Red (R)
Audio Cable
L
R
AUDIO
OUT
HDMI
ARC
HDMI
EXTERNAL DEVICE
TV PORT
HDMI Cable
Audio device
TV PORTS
EXTERNAL DEVICE
USB
DC 5V 1A(MAX)
USB
DC 5V 0.5A(MAX)
