2.3 Ties,clamps and tapes:

to show the positions where ties and clamps and tapes should be, for checking after

servicing, Before disassemble the TV ,besure to take photes for the TV assembly example

for HE55A7000EUWUTS.

2.2 TV boards part list

Main board Boards function difference

Main chassis type

For Series

RSAG7.820.8698\ROH

1. Lateral terminal and vertical terminal.

2. TCON part not on the board.

MSD6886

HE55A7000EUWTS

55A6500EE

Hisense MSD6886 User Manual
