If you wish to connect hot and cold water supply (Fig.1):
1. Fix the red marked inlet hose to the hot water tap and to the inlet valve with
the red filter on the rear side of machine.
2.
Fix the other inlet hose to the cold water tap and to the inlet valve with the
blue filter on the rear side of the machine.
Make sure:
a) The connections are tightly fixed
b)
If you wish to connect only the cold fill follow the below instructions (Fig. 2):
1. You will need a Y-piece connector. This can be purchased from local
hardware or plum b ing supplier.
2. Fix the Y-piece connector to the cold fill tap.
3. Connect the two inlet valves present on the rear part of the machine
to t h e Y - p i e c e connector using the hoses provided.
Hot / Cold fill fault - For Models with Dual Inlets
Do not invert their position (for example: cold fill into hot inlet valve and vice
versa).
Fig.1
Hot fill
Red inlet valve
Blue inlet valve
Cold fill
Red inlet valve
Blue inlet valve
Cold fill
Y-piece
Fig.2
If the laundry is still too wet at the end of the cycle, remove some articles of
laundry and repeat the spin cycle.
Excessive foam formation may prevent spinning. Use the correct amount
of detergent.
Check that the spin speed selector has not been set to “0”.
27
