NIVERSAL SYMBOLS
As a guide to the operation of your vehicle, various universal symbols have been utilized on the
instruments and controls. The symbols are shown below with an indication of their meaning.
Safety Alert Symbol
Lift Cylinder-Retract
Diesel Fuel Lift Cylinder-Extend
Engine coolant-Temperature
Lift Cylinder-Float
Parking Brake
Hazard Warning Lights
Battery Charging Condition
Master Lighting Switch
Engine Oil-Pressure
Audible Warning Device
Turn Signal/Hazard
Fault indicator light of EPS system
Differential Lock
2WD/ 4WD
Position light bulb
