73
ENGLISH
PRODUCT SPECIFICATIONS
SPECIFICATION
Panel
Display dimensions
Approx. 32 inches
(698 (H) x 392 (V) mm, diagonal 801mm)
Approx. 37 inches
(820 (H) x 461 (V) mm, diagonal 941mm)
Resolution 1366 (H) x 768 (V) pixels 1366 (H) x 768 (V) pixels
Net dimensions
including Stand:
813(W)x663(H)x350(D) mm
excluding Stand:
813(W)x584(H)x114(D) mm
including Stand:
940(W)x736(H)x350(D) mm
excluding Stand:
940(W)x657(H)x119(D) mm
Net weight
including Stand: 28.0kg
excluding Stand: 22.3kg
including Stand: 32.5kg
excluding Stand: 26.8kg
Ambient
conditions
Temperature Operating : 5°C to 35°C, Storage : 0°C to 40°C
Relative humidity Operating : 20% to 80%, Storage : 20% to 90% (non-condensing)
Power supply
AC220 - 240V, 50Hz
Power consumption/ at standby
163W/<1W 195W/<1W
Audio output speaker total 20W speaker total 20W
(VIDEO input)
Input terminals
AV1 : composite video input terminal (SCART)
S video input terminal (SCART)
L/R audio input terminal (SCART)
AV2•3 : composite video input terminal (SCART)
RGB video input terminal (SCART)
L/R audio input terminal (SCART)
AV4 : composite video input terminal (RCA)
component video input terminal.(RCA)
L/R audio input terminal (RCA)
AV5 : composite video input terminal (RCA)
S video input terminal (Mini DIN)
L/R audio input terminal (RCA)
HDMI 1•2 : HDMI input terminal
Audio input terminal (3.5mm Stereo Mini Jack)
Photo Input : Photo Input terminal / SD card slot
Input signals
Composite video: PAL, SECAM, NTSC3.58, NTSC4.43, PAL60
Component video: 480i, 576i, 480p, 576p, 720p/50, 720p/60, 1080i/50, 1080i/60
Output Signal
OUTPUT (MONITOR): composite video monitor-output terminal (RCA)
OUTPUT (MONITOR): L/R audio monitor- output terminal (RCA)
OUTPUT (HEADPHONE): L/R audio monitor- output terminal (Mini-pin)
OUTPUT (SUB-WOOFER): Woofer output terminal
AV1 : composite video output terminal (SCART)
L/R audio output terminal (SCART)
AV2•3 : composite video output terminal (SCART)
L/R audio output terminal (SCART)
(RF input)
Input terminal / Receiving range ANT : 75Ω Unbalanced / 44~870MHz
RF Video System
PAL B, G, H / I / D, K
SECAM B, G / K1 / L, L' / (D,K)
DVB-T*
(RGB input)
Input terminals
Analogue RGB input terminal (D-sub 15-pin)
Audio input terminal (3.5mm Stereo Mini Jack)
Input signals 0.7 V/1.0 Vp-p, analogue RGB (Recommended Signal)
Sync signals
H/V separate, TTL level [2KΩ]
H/V composite, TTL level [2KΩ]
Sync on green, 0.3 Vp-p [75Ω]
The unit takes at least 30 minutes to attain the status of optimal picture quality.
The SECAM D, K system might not be normally received, depending on the model.
The DVB-T system is available only for 9700 models.
To Next Page
