3. Component names
 Main unit
Control panel
 Al Adjustment buttons are located on the bottom of
the control panel
 Indications for each button's function can be found
on the inside of the control panel cover.
1. POWER
4. RIGHT X 7. SELECT
2. CHANNEL S 5. VOL W
2. UP S 5. LEFT W
3. CHANNEL T
6. INPUT
3. DOWN T 6. EXIT Normal Button Action
4. VOL X 7. MENU
Button Action when MENU engaged
Power lamp
Remote-control receiver
Main power switch
The main
power switch is
locate
d at the
back, on the
right side.
