SLIDE COMPOUND MITER SAW MODEL NO. C 10FSHC
PARTS LIST
A B CDEA B CDE
372093 083Z CORD CLAMP 1 372499 32RA NUT CHUCK M6*1.0 T=6 2
372441 0CES COMPRESSION SPRING 1 372500 32RC NUT CHUCK
M12*1.75 T=12 1
372442 0CPD CENTER BOLT 1 372501 33N7
FLAT WASHER φ6*16-1.5 2
372443 0D9A ANCHOR BLOCK 1 372502 34BN COMPRESSION SPRING 1
372444 0DT4
ROLLING WHEEL 2 372503 387B HEX. SOC. TRUSS HD. & WASHER ASS'Y M6*1.0-12 2
372445 0DT7 BEARING 2 372504 39XD COMPRESSION SPRING 1
372446 0DVJ BLADE WRENCH 1 372505 3ADS HEX. NUT M6*1.0 T=5 2
726478 0J4F FLAT WASHER φ8*16-2.5 1 339796 3ADZ NUT CHUCK
M10*1.5, T=10 1
327352 0J66 FLAT WASHER φ4*10-1 1 339832 3AE3 FLAT WASHER φ10*20-31
949434 0J7K FLAT WASHER
3/8*29/32-5/64 1 372508 3AZ7 CR. RE. PAN HD. SCREW M5*0.8-16 3
372450 0JA7
EXTERNAL TOOTH LOCK WASHER φ6 3 372509 3BKD HINGE 1
372018 0JAZ WAVE WASHER 2 372510 3DJ8 LOCATING BAR 1
327354 0JB0
WAVE WASHER 2 372511 3DJ9 FRAME ENDCAP 1
372453 0JBG DISC SPRING WASHER φ12 1 372512 3DJA WASHER BEARING 1
372454 0JE7 C-RING 1 372513 3DJG SPACER 2
372455 0JFB SELF-LOCKING RING 2 372514 3DJL SET PLATE 1
372456 0JMN O-RING 1 372515 3DJP SLIDE CARRIAGE ASS'Y 1
372050 0JMP O-RING 1 372516 3DJR SLIDE CARRIAGE 1
372458 0JNR
O-RING ROD 2 372517 3DKF SHAFT-PIVOT 1
372459 0JPE HEX. HD. BOLT M6*1.0-20 2 372518 3DKJ TORSION SPRING 1
372460 0JUK HEX. SOC. HD. CAP BOLT M6*1.0-16 1 372519 3DMM BEARING COVER 3
968247 0JX9
HEX. SOC. SET SCREW M6*1.0-10 1 372520 3DTM SHAFT SLEEVE 1
726318 0K05
HEX. SOC. TRUSS HD. SCREW M8*1.25-20 4 372521 3DTZ RUBBER PAD 1
726539 0K2B HEX SOC. HD. CAP SCREW M6*1.0-16 1 372522 3DWT INSERT 1
372464 0K4S
CR. RE. TRUSS HD. SCREW M5*0.8-16 2 372523 3DXM LINEAR MOTION BEARING 1
372465 0K5E CR. RE. COUNT HD. SCREW M6*1.0-25 1 372524 3FJH SET PLATE 1
372466 0KD8 CR. RE. PAN HD. SCREW M4*0.7-12 1 372525 3FJQ WRENCH SET 1
949236 0KDH CR. RE. PAN HD. SCREW M5*0.8-8 1 372730 3FQM SPACER 1
726615 0KQW LOCK NUT M5*0.8,T=5 1 372526 3FVK LASER_COVER 1
339840 0KQX NUT M6*1.0,T=6 1 372527 3FVL COVERLASER_COVER 1
372073 0KQY LOCK NUT M8*1.25,T=8 1 372528 3FVM LEVELING PAD 1
314474 0KR3 LOCK NUT M6*1.0 T=6 1 372529 3FVQ ADJUSTABLE NUT 1
372472 0KTP CABLE CLAMP 1 372530 3G3T
MITER DETENT OVERRIDE BUTTON 1
726627 0KUW TERMINAL 4 372531 3G4S VISE ASS'Y 1
372474 10KD ROLL PIN 2 372532 3GGH SPECIAL BOLT 1
372475 22A4 LOCKING CABLE TIE 1 372533 3GGQ ARM MITER COVER 1
372476 23NX GUARD-CORD 1 372534 3GGS BRACKET(B) 1
372477 25B1 CR. RE. TRUSS HD. SCREW M5*0.8-25 1 372535 3GGT BRACKET(A) 1
372478 27PF COMPRESSION SPRING 1 372536 3GJ8 INDICATOR (FOR BEVEL SCALE) 1
372479 2B7H
HEX. SOC. SET SCREW 2 372537 3H38 LOCK-OFF BUTTON 1
372480 2E35 TRIGGER SWITCH 1 372538 3H3E TORSION SPRING 1
372481 2F39 LOCKING PIN 1 372539 3H9P POWER CABLE 1
372024 2JHZ
CR. RE. PAN HD. TAPPING SCREW M5*0.8-12 3 372540 3H9U LEAD WIRE ASS'Y 1
372483 2JTR
INSULATING SLEEVE 1 372541 3HHM CR. RE. COUNT HD. SCREW M4*0.7-84
372484 2M0S LIMIT SWITCH 1 372542 3HHT CR. RE. TRUSS HD. SCREW M6*1.0-81
372485 2MX6
CR. RE. PAN HD. SCREW & WASHER M6*1.0-20 4 372543 3HHU CR. RE. TRUSS HD. SCREW M5*0.8-63
372486 2NAH CR. RE. TRUSS HD. SCREW M4*0.7-8 1 372544 3HHX
CR. RE. PAN HD. TAPPING SCREW M4*18-16 3
372487 2RXR CR. RE. PAN HD. SCREW M4*0.7-8 1 372545 3HHZ
CR. RE. PAN HD. TAPPING SCREW M4*18-25 1
372488 2RYJ
CR. RE. PAN HD. TAPPING SCREW M4*16-20 3 372546 3HJ0 CR. RE. PAN HD. TAPPING SCREW M3*24-8 4
372489 2VEP
SHAFT 1 372547 3HJ3 CR. RE. PAN HD. ROUND NECK SCREW M6*1.0-12 1
372490 2VH6 LINEAR MOTION BEARING 2 372548 3HJ5 CR. RE. PAN HD. SCREW M5*0.8-61
372491 2VN7 BLANKET WASHER 4 372549 3HJ7 CR. RE. PAN HD. SCREW M5*0.8-88
372492 2VS0 LEAD WIRE ASS'Y 1 372550 3HJ8 CR. RE. PAN HD. SCREW M5*0.8-55 2
372493 2WK0 COMPRESSION SPRING 1 372551 3HJA CR. RE. PAN HD. SCREW M5*0.8-25 1
372494 2WX6 WASHER (A)/(B) 2 372552 3HJB CR. RE. PAN HD. SCREW M5*0.8-10 6
372495 2XSF
CR. RE. COUNT HD. TAPPING SCREW M5*16-8 3 372553 3HJF HEX. SOC. SET SCREW M6*1.0-16 2
372496 2YR6 SPRING GUARD 1 372554 3HJG HEX. SOC. SET SCREW M6*1.0-10 2
372497 306G BUSHING 1 372555 3HJH HEX. SOC. HD.CAP SCREW M5*0.8-40 2
372498 31VX
CR. RE. TRUSS HD. ROUND NECK SCREW M6*1.0-14 1
