SLIDE COMPOUND MITER SAW MODEL NO. C 10FSHC
PARTS LIST
A
B
CDEA
B
CDE
372556 3HJP
HEX. SOC. TRUSS HD. & WASHER ASS'Y
M6*1.0-16 2 372597 3TU2 COVER PLATE 1
372557 3HJU HEX. WASHER HD. BOLT M8*1.25-20 1 372598 3TU3 LOWER GUARD 1
372558 3HJW HEX. NUT M5*0.8,T=4 1 372599 3TU4
BRACING PLATE
1
372559 3HK1 FLAT WASHER φ12*21-1 1 372600 3TU6 CABLE COVER 1
372560 3HK2
FLAT WASHER
φ5*14-1 1 372601 3TU7
LAMP SOCKET
1
372561 3HK3 FLAT WASHER φ6*12-1 2 372602 3TU8 SWITCH HANDLE(RIGHT) 1
372562 3HKB HEX. SOC. SET SCREW M6*1.0-12 1 372603 3TU9 SWITCH HANDLE(LEFT) 1
372563 3J7N
CR.RE. PAN HD. TAPPING SCREW
M4*16-16 1 372604 3TWF CONTROLLER ASS'Y 1
372564 3JE7 HEX. SOC. HD. CAP SCREWS M5*0.8-20 1 372605 3TWK
LED LIGHT
1
372565 3VUA CAUTION LABEL 1 372606 3TWL INSERT 1
372566 3K0U ANCHOR PLATE 1 372607 3TWW MOTOR ASS'Y 1
372567 3K0V
CR. RE. TRUSS HD. ROUND NECK SCREW
M6*1.0-10 1 372608 3U2U STOP KNOB 1
372568 3KJ1
INSULATING SLEEVE
φ8.5-50 1 372609 3U6Q LABLE LINE COVER 1
372569 3M9D SET PLATE 1 372610 3UG6 TABLE INSERT 2
372570 3MAR SUPPORT ROD PAD 2 372611 3UMM
LABEL
1
372571 3MAS SUPPORT ROD 2 372612 3UMN MITER SCALE 1
372572 3MFB ALLEN BOLT M5*0.8-35 1 372613 3UMQ CAUTION LABEL 1
372573 3R9Z
CR. RE. PAN HD. TAPPING SCREW
M5*0.8-35 1 372614 3UMR CAUTION LABEL 1
372574 3S85
SLIDE PLATE
1 372615 3UMS CAUTION LABEL 1
372575 3S9R NEEDLE ROLLER 8 372616 3UMT WARNING LABEL 1
372576 3SG0 INDICATOR (FOR MITER SCALE) 1 372617 3UMU WARNING LABEL 1
372577 3TMD
HEX. SOC. HD. CAP SCREW
M6*1.0-14 3 372618 3UMV WARNING LABEL 1
372578 3TRD
DUST BUG
1 372619 3UMW INSTRUCTIONS MANUAL 1
372579 3TTF BASE 1 372620 3UN5 CABLE SHIELD 1
372580 3TTG
FENCE
1 372621 3UNA LASER ASS'Y 1
372581 3TTH SUB FENCE(B) 1 372622 3V10 STOP PLATE(A) 1
372582 3TTJ SUB FENCE(A) 1 372623 3V11 STOP PLATE(B) 1
372583 3TTK CLAMP BOLT 1 372624 3V19 HOLDER(A) 1
372584 3TTL LOCK KNOB 2 372625 3V1R
CR. RE. TRUSS HD. ROUND NECK SCREW
M5*0.8-12 2
372585 3TTM SLIDE SECURING KNOB 1 372626 3VAC LASER STICKER 1
372586 3TTN VISE LOCK KNOB 2 372627 3VAD WARNING LABEL 1
372587 3TTP TURN TABLE 1 372628 3VAE TILTING SCALE 1
372588 3TTQ POSITIVE STOP LOCK BUTTON 1 372629 3VKC ROLL PIN 1
372589 3TTR MITER LOCK HANDLE 1 372630 3VLV CARRIAGE HANDLE 1
372590 3TTS BEVEL LOCK HANDLE 1 372631 3VMT BUSH 4
372591 3TTT PLUNGER HANDLE 1 372632 3VN4 SAW BLADE 1
372592 3TTV SPECIAL NUT 1 372633 3VQA LED/LASER SWITCH ASS'Y 2
372593 3TTW LOCATING BAR 1 372634 3VQB CAUTION LABEL 1
372594 3TTY LOCKING ROD 1 372731 3VTE STOP PLATE 1
372595 3TTZ
BRACKET STOP
1 372635 Y43S
CR. RE. TRUSS HD. ROUND NECK SCREW
M6*1.0-15 1
372596 3TU1 LEVER 1
000BookC10FSHCNA.indb128000BookC10FSHCNA.indb128 2017/06/2018:38:112017/06/2018:38:11
