Hitachi C 8FSE - Page 56

PART
S
C 8FSHE
DESCRIPTION REMARKS
1 935-196 MACHINE SCREW (W/WASHERS) M4X12 (BLACK) 1
2 312-488 CLAMP LEVER 1
3 329-409 BOLT (LEFT HAND) D10 1
4 965-077 SPECIAL WASHER 1
5 325-028 SET PIN 1
6 996-407 O-RING (1AP-12) 1
7 949-215 MACHINE SCREW M4X8 (10 PCS.) 5
8 949-429 BOLT WASHER M4 (10 PCS.) 6
9 320-141 HINGE SHAFT (A) 1
10 329-417 SCALE (B) 1
11 329-408 LINER (A) 1
12 312-481 SPRING 1
13 329-422 TURN TABLE 1 INCLUD. 10
14 329-418 SHAFT (B) 1
15 949-437 BOLT WASHER M12 (10 PCS.) 2
16 949-217 MACHINE SCREW M4X12 (10 PCS.) 1
17 321-329 INDICATOR 1
18 949-256 MACHINE SCREW M6X16 (10 PCS.) 6
19 329-421 TABLE INSERT 2
20 321-342 SPACER (A) 1
21 329-416 SHAFT (A) 1
22 673-489 RETAINING RING (E-TYPE) FOR D5 SHAFT 1
23 322-283 SIDE HANDLE 1
24 321-339 LEVER SHAFT 1
25 321-338 LEVER 1
26 321-340 SPRING (D) 1
* 27 CAUTION LABEL (D) 1
* 27 CAUTION LABEL (C) 1
28 329-415 SHAFT (C) 1
29 987-860
SEAL LOCK HEX. SOCKET SET SCREW M6X6 1
30 321-417 SPRING (E) 1
31 322-280 STOPPER (A) 1
32 324-395 COVER (B) 1
33 875-249 THRUST WASHER 1
34 321-336 PIN COVER 1
35 302-522 KNOB BOLT M10X66 1
36 301-806 WING BOLT M6X15 1
37 SCREW HOLDER 1
38 949-432 BOLT WASHER M6 (10 PCS.) 1
39 329-859 VISE SHAFT 1
40 302-532 VISE PLATE 1
41 949-216 MACHINE SCREW M4X10 (10 PCS.) 1
42 329-860 VISE ASS'Y 1 INCLUD. 35-41
43 949-678 BOLT M8X35 (10 PCS.) 4
44 949-457 SPRING WASHER M8 (10 PCS.) 4
45 949-433 BOLT WASHER M8 (10 PCS.) 4
46 307-937 WING BOLT (A) 1
47 329-420 FENCE (B) 1
48 963-837 NYLON NUT M6 1
49 329-465 PLATE 1
- 4 - 2 - 08
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
