Hitachi CB 13F - Parts List

–
24
–
English
12” (305mm) BAND SAW
MODEL NO. CB13F
PARTS LIST
FOR SCHEMATIC A
Always order by I.D. Number
PARTS
LIST
Parts No.
I.D.
Description
Size
QTY
Parts No.
I.D.
Description
Size
QTY
726875
X1VV
SCREW(CROSS HEAD)W/I WASHER
3/16*3/8
13
726916
X22F
SET SCREW(HEADLESS)
M6*16
4
726876
X1W2
CROSS HEAD SCREW
3/16*1/4
2
726917
X22H
HEADLESS CROSS SCREW
3/16*3/8
2
726878
X1ZU
STEEL BALL
1/4
1
726918
X22K
CROSS HEAD SCREW
3/16*3/8
2
726879
X217
BEARING SHAFT
2
726919
X22L
STRAIN RELIEF BUSHING
6N-4
2
726880
X218
SHAFT OF LOWER WHEEL
1
726920
X22M
SAFETY SWITCH
4P J9301A
1
726881
X219
SHAFT OF UPPER WHEEL
1
726921
X22N
BALL BEARING
626ZZ
2
726882
X21A
POWER CORD STORAE
2
726922
X22P
BALL BEARING
6202ZZ
3
726883
X21B
GUARD
ABS
1
726923
X22Q
POWER CORD W/PLUG
1
726884
X21C
HEX. FIXTURE BOLT
2
726924
X22R
POWER CORD W/INSERT PLUG
1
726885
X21D
CLIP HEAD
2
726925
X22S
BEARING COVER
2
726886
X21E
BLADE GUARD, LOWER
1
726926
X22T
LOWER SUPPORT BKT
1
726887
X21F
PLASTIC BRUSH ASSY.
1
726927
X22U
Y TYPE BLOCK
2
726888
X21G
PIN
2
726928
X22V
UPPER GUIDE HOLDER ASSY.
1
726889
X21H
PIN FIXTURE BOLT
3
726929
X22W
FRAME ARM COVER, LOWER
1
726890
X21J
ADJUST KNOB ASSY.
1
726930
X22X
FRAME ARM COVER, UPPER
1
726891
X21K
UPPER WHEEL SHAFT HINGE
1
726931
X22Y
UPPER COVER, INNER
1
726892
X21L
SLIDING BKT.
1
726932
X22Z
UPPER ARM
1
726893
X21M
GUIDE POST (V TYPE)
1
726933
X231
BASE
1
726894
X21N
STEEL PIN
1/4*25
4
726934
X232
PLATE
2
726895
X21P
PIN
1/4*16
2
726935
X233
COMPLETED MOTOR W/CORD
1
726896
X21Q
ADJUST SPRING
1
726947
X23H
SPRING WASHER
3/16
2
726897
X21R
SPRING
1
726948
X23J
HEX.NUT
5/16
1
726898
X21S
STAR KNOB
5/16*2
1
726951
X23M
HEX.SCREW
5/16*1-1/4
1
726899
X21T
KNOB
3/8*1-1/4
1
X23T
LOWER GUIDE HOLDER ASSY.
1
726900
X21U
STAR KNOB
5/16*1-1/4
1
726954
X23R
SCREW (CROSS HEAD)W/I WASHER
3/16*1/4
2
726901
X21V
C RING
S-15
1
726966
X247
CROSS HEAD SCREW W/I WASHER
3/16*1/2
1
726902
X21W
KEY
5*5*54
1
726971
X25U
POST SEAT
1
726903
X21X
FLAT KEY
5*5*32.5
1
726972
X25V
MOTOR LABEL
1
726904
X21Z
TOOTH WASHER
5
2
726973
X25W
GUIDE SUPPORT BRACKET BLADE GUARD
1
726905
X221
STEEL WASHER
5/16-23*2.
3
726974
X25X
COPPER WASHER
2
726906
X223
FLAT WASHER
3/8*23
1
726975
X25Y
STEEL WASHER
3/16-14
4
726907
X224
FLAT WASHER
3/8*19
1
726976
X25Z
FLAT WASHER
3/4
2
726908
X225
FLAT WASHER
1/4
2
726977
X260
NYLON NUT
3/4
1
726909
X227
SPRING WASHER
3/4
1
726978
X261
HEX. SCREW
3/8*1-1/2
1
726910
X228
SQUARE NUT
1
726979
X262
HEX. SCREW
3/4*2-1/2
1
726911
X229
BUTTERFLY NUT
5/16
1
726980
X263
HEX. SCREW
1/4*3/4
2
726912
X22B
HEX. NUT
3/4
1
726981
X264
MOTOR PULLEY
Ø50-Ø76
1
726913
X22C
SCREW (HEADLESS)
5/16*5/16
1
726985
X26C
SPRING PIN
Ø3X30
1
726914
X22D
SET SCREW
1/4*1/4
5
726990
X26P
STEEL WASHER
3/8*19
2
726915
X22E
SET SCREW
1/4*1/2
4
X21J
X21M
X25W
X22D 5
X21k
X21S
X229
X21G 2
X21L
X21Q
X219
X25U
X217 2
X228
X22Z
X22U 2
X21N 4
X22V
X22C
X21R
X1ZU
X21U
X247
X21A 2
X22Q
X22R
X22L 2
X25V
X22K 2
X22S
X21V
X22P 2
X23R 2
X25X 2
X21Z 2
X262
X23T
X225 2
X22Y
X263 2
X22T
X25Y 4
X1VV 13
X21C 2
X1W2 2
X23H 2
X21H 2
X21B
X221 2
X22H 2
X22N 2
X22E 4
X21E
X26P 2
X21D 2
X22X
X22M
X21W
X218
X22P
X21H
X21F
X22W
X260
X23J
X221
X23M
X22B
X227
X25Z 2
X22F
X264
X224
X261
X233
X223
X21T
X26C
X21P 2
X232 2
X21X
X231
