Hitachi CB 13F - Page 26

–
26
–
English
Parts No.
I.D.
Description
Size
QTY
Parts No.
I.D.
Description
Size
QTY
726874
X1V7
SPRING WAHSER
5/16
6
726957
X23X
LOWER DOOR
1
726908
X225
FLAT WASHER
1/4
1
726958
X23Z
PULLEY
Ø180-Ø163
1
726918
X22K
CROSS HEAD SCREW
3/16*3/8
1
726959
X240
HEX. WRENCH
3mm
1
726936
X234
TABLE INSERT
2.5mm
1
726960
X241
HEX . SCREW
1/4*1/4
1
726937
X235
TRUNNION CLAMP SHOE
2
726961
X242
UPPER WHEE L ASSEMBLY
1
726938
X236
CUTTING BLADE
80*3/8*0.5
1
726962
X243
UPPER WHEE L ASSEMBLY
1
726939
X238
TRUNNION
2
726963
X244
V-BELT
A-26
1
726940
X239
DUST COLLECTIOOON HOSE
1
726964
X245
TRUNNION BRACKET
1
726941
X23A
SCALE
45
1
726982
X265
NAMEEPLATE
1
726942
X23B
HINGE LOWER
1
726984
X267
PUSH/PUL L LABLE
1
726943
X23C
MTTER GAUGE ASSY.
1
726986
X26J
EXTENSION TUBE W/KNOB RIGHT
1
726944
X23D
POINTER
MT-2000P
1
726987
X26K
FLAT WASHER FOR LOWER WHEEL
1
726945
X23F
SPRING PI N
3*10
1
726988
X26M
WHEEL PROTECTOR
1
726946
X23G
HLAT WASHER
5/16*18
2
726989
X26N
HINGE UPPER
1
726947
X23H
SPRING WASHER
3/16
1
726991
X26Q
CLAMP SHOE ASSEMBLY
2
726948
X23J
HE X.NUT
5/16
1
726993
X26S
KNOB
10
2
726949
X23K
NUT
3/16
12
726994
X26T
KNOB
3/8
2
726950
X23L
HE X.NUT
1/2
1
726995
X26U
HEX . SCREW
M10*40
2
726951
X23M
HE X.SCREW
5/16*1-1/4
2
726996
X26V
TABLE
1
726952
X23N
HE X.SCREW
5/16*1
1
726997
X26W
WARNING LABEL
1
726953
X23P
HE X. SCREW
1/4*5/8
7
726998
X2BF
LOWER WHEEL
1
726954
X23R
CR. HEAD SCREW W/WASHER
3/16*1/4
1
726999
X2BG
UPPER WHEEL
1
726955
X23S
BA LL BEARING
6002ZZ
2
X2D7
CROSS HEAD SCREW
3/16*1/4
1
726956
X23W
UPPER DOOR
1
X2D8
TABLE PIN
1
12” (305mm) BAND SAW
MODEL NO. CB13F
PARTS LIST
FOR SCHEMATIC B
Always order by I.D. Number
X242
X26M
X23N
X23J
X26U 2
X235 2
X1V7 6
X23P 6
X26Q 2
X238 2
X23A
X23D
X23H
X22K
X23M 2
X23G 2
X23S 2
X23L
X23K 12
X245
X26S 2
X243
X267
X23C
X234
X23F
X2D8
X26V
X26J
X26W
X265
X241
X225
X239
X26T 2
X23X
X26K
X23P
X2BF
X23R
X2D7
X23B
X240
X23Z
X2BG
X244
X236
X26N
X23W
