Español
49
ITEM NO. PART NAME
1 MACHINE SCREW (W/WASHERS) M6 × 20
4 SAFETY COVER ASSEMBLY
6 SUB COVER
7 SCREW (G) M10 × 20
8 WASHER (A)
9 WHEEL WASHER
10 CUT-OFF WHEEL (C)
11 MACHINE SCREW M4 × 8
12 SPRING WASHER M4
13 BOLT WASHER M4
14 STOPPER SPRING
15 HITACHI LABEL
16 COLLAR (F)
17 NUT M4
18 NUT M6
19 BRUSH CAP
20 CARBON BRUSH AUTO STOP (1 PAIR)
21 BRUSH HOLDER
22 RIVET D2.5 × 4.8
23 STOPPER
26 WING BOLT M6 × 10
27 BALL BEARING 6206VV CM PS2S
28 BEARING COLLAR
29 SPINDLE
30 BALL BEARING 6201VV CM PS2S
31 BALL BEARING 6202VV CM PS2S
32 BEARING LOCK
33 ARMATURE ASSEMBLY 115V
34 FUN GUIDE
35 DUST SEAL
36 BALL BEARING 6300VV CM AV2S
37 BEARING BUSHING
38 MACHINE SCREW M6 × 22
39 SPRING WASHER M6
40 WASHER (H)
41 COLLAR (F)
42 VINYL TUBE
43 STATOR ASSEMBLY 115V
44 BRUSH TERMINAL
45 HOUSING ASSEMBLY
46 WHEEL COVER
47 TAIL COVER
49 TAPPING SCREW D4 × 10
50 NAME PLATE
51 MACHINE SCREW M4 × 10
52 CORD CLIP
53 CORD ARMOR D10.7
54 SWITCH (A) (2P PILLAR TYPE) W/LOCK
55 TAPPING SCREW (W/SP. WASHER) D5 × 80
56 SET PIECE
57 BOLT WASHER M4
58 SPRING WASHER M4
59 TAPPING SCREW D4 × 10
60 CHAIN HOOK
61 SPRING WASHER M6
62 MACHINE SCREW M6 × 20
63 SWITCH HANDLE
64 HANDLE COVER
65 BOLT WASHER M4
66 SLOTTED HD. SET SCREW M4 × 8
67 TAPPING SCREW (W/SP. WASHER) D4 × 25
68 CLUTCH
69 BOLT
ITEM NO. PART NAME
70 BOLT WASHER M8
71 SPLIT PIN D3 × 15
72 VISE (A)
73 BOLT M10 × 20
74 BOLT WASHER M10
75 VISE (B)
76 CORD
77 CHAIN
78 RETAINING RING (E-TYPE) FOR D6 SHAFT
79 COLLAR
80 SCREW
81 MACHINE SCREW M8 × 25
82 SPRING WASHER M8
83 WASHER M8
84 SCREW HOLDER
85 BOLT WASHER M6
86 ROLL PIN D6 × 30
87 RUBBER EDGE
88 BOLT WASHER M6
89 TAPPING SCREW (W/SP. WASHER) D5 × 50
90 BASE ASSEMBLY
91 BOLT WASHER M16
92 SPRING (B)
93 SPRING (A)
94 GEAR CASE ASSEMBLY
95 HEX SOCKET SET SCREW M5 × 16
96 SHAFT
97 BASE RUBBER
98 BOLT WASHER M6
99 SPRING WASHER M6
100 MACHINE SCREW M6 × 16
101 WASHER (A)
102 SPRING WASHER M10
103 NUT M10
104 SPARK CHUTE
105 SPRING WASHER M5
106 MACHINE SCREW M5 × 10
107 NUT M8
108 HEX. SOCKET HD. BOLT M8 × 25
109 QUICK LOCK VISE ASSEMBLY
110 SPRING WASHER M8
111 STOPPER (A)
112 CAUTION PLATE
116 LOCK-OFF BUTTON
127 CAUTION PLATE
128 CAUTION PLATE (A)
133 FILTER SEAL (C)
134 RETAINRING RING (C-TYPE) FOR D15 SHAFT
501 SPANNER
Cut-Off Machine Parts List
