Part names (continued)
Remote control
(1) INPUT button (
24)
(2) IWB button *
(3) CALIBRATION button *
(4) STANDBY/ON button (20)
(5) ASPECT button (24)
(6) AUTO button (26)
(7) ACCENTUALIZER button (27)
(8) HDCR button (27)
(9) FOCUS - button (26)
(10) FOCUS + button (26)
(11) D-ZOOM - button (25)
(12) D-ZOOM + button (25)
(13) PAGE UP button (19)
(14) MAGNIFY - ON button (29)
(15) MY BUTTON - 1 button (62)
(16) VOLUME + button (23)
(17) PAGE DOWN button (19)
(18) MAGNIFY - OFF button (29)
(19) MY BUTTON - 2 button (62)
(20) VOLUME - button (23)
(21) KEYSTONE/PERFECT FIT button (28)
(22) TEMPLATE button (27)
(23) FREEZE button (30)
(24) AV MUTE button (23)
(25) ESC button (31)
(26) MENU button (31, 32)
(27) ENTER button (31, 32)
(28) POSITION button (28, 32)
(29) RESET button (31)
(30) ▲/▼/◄/► cursor buttons (31)
(31) Battery cover (17)
Back of
the remote control
(31)
CALIBRATION
KEYSTONE/
ASPECT
ACCENTUALIZER
HDCR
AV MUTE
POSITION
ESC MENU
RESET
IWB
AUTO
PAGE
DOWN
ON
OFF
FREEZE
UP
1
2
ENTER
FOCUS
-
+
D-ZOOM
-
+
＋
ー
VOLUME
MAGNIFY
MYBUTTON
INPUT
PERFECT FIT TEMPLATE
(2)
(1)
(6)
(5)
(10)
(9)
(13)
(14)
(17)
(18)
(21)
(22)
(25)
(30)
(28)
(3)
(4)
(7)
(8)
(11)
(12)
(16)
(15)
(20)
(19)
(24)
(23)
(26)
(27)
(29)
• Any button marked with “*” is not supported on this projector (106).NOTE
