Hitachi CP-AX2503 Specifications

CP-AX2503 LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories
Supplied
Accessories
Remote control, power cord,
computer cable, user's manual,
network manual
Optional
Accessories
HAS-WM03 wall mount, wall plates,
wall adapter, USBWL11N USB wireless
adapter, MS-1 wired and MS-1WL
wireless multifunction switchers,
TT-03 tabletop stand
Replacement Parts
Lamp DT01511 with filter
Remote Control HL03033
Filter UX37191
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA 1024 x 768
White Light Output 2,700 ANSI lumens
Color Light Output 2,700 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 / 16:9 and 16:10 compatible
Contrast Ratio 5000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
0.2 : 1 from edge of projector to screen
0.3 : 1 from mirror cover to screen
Focus Distance 15" - 26" from mirror cover to screen
Display Size 60" - 100"
Lens & Operation
Lens F = 1.8, f = 4.21 mm
Lamp Wattage 225W
Expected Lamp Life* Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Expected Filter Life** Approximately 4,000 hours
Speaker Output 16W x 1
Keystone H and V: +/- 5º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+/SXGA/WSXGA+/UXGA
(compressed), MAC 16"
H-Sync 15 kHz - 106 kHz
V-Sync 50 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1 (shared with computer in 2)
Video Input
S-Video N/A
Composite Video RCA jack x 1
Component Video 15-pin D-sub x 2 (shared with computer in 1/2)
Audio Input 3.5 mm stereo mini jack x 1, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output 3.5 mm stereo mini jack x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 330W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 14.8" x 14.2" x 5.4" (excluding protruding parts)
Weight Approximately 9.5 lbs
Approvals UL 60950-1 / cUL, FCC part 15 subpart B Class B
Warranty 3 year limited parts and labor
Extended Service Contract available (additional cost)
Projection Throw Chart (In inches)
Screen Size 4:3 Throw Distance
Diagonal Distance from
edge of projector
to screen
Distance from
mirror cover
to screen
60 4.1 15.2
70 6.7 17.8
80 9.3 20.4
90 11.9 23.0
100 14.5 25.6
Throw Ratio: (distance : width)
0.2 : 1 from edge of projector
0.3 : 1 from mirror cover
CP-AX2503
Hitachi America, Ltd.
Toll Free: 1.800.HITACHI
•
Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
HI0259-Rev.1-04/14
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2014 Hitachi America, Ltd. All Rights Reserved .
Ultra Short Throw
Series

Hitachi CP-AX2503 Specifications

General

Matrix size	0.63 \
Number of colors	16.78 million colors
Native aspect ratio	4:3
Projection distance	- m
Projection technology	3LCD
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	5000:1
Screen size compatibility	60 - 100 \
Projector native resolution	XGA (1024x768)
Projector brightness (economic mode)	1800 ANSI lumens
Throw ratio	0.3:1
Digital zoom	1.35 x
Focal length range	- mm
Lamp power	225 W
Light source type	Lamp
Lamp power (economic mode)	5000 W
Service life of light source	3000 h
3D	No
Full HD	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Composite video in	1
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
VGA (D-Sub) ports quantity	3
HDCP	-
Noise level	34 dB
Certification	UL/C-UL, FCC, AS/NZS CISPR22, CE, GOST-R
Noise level (economic mode)	28 dB
RMS rated power	16 W
Placement	Desktop, Ceiling
Product type	Standard throw projector
Product color	White
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	320 W
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	360 mm
Width	377 mm
Height	136 mm
Weight	4300 g
