Hitachi CP-WU8440 Brochure & Specs

CP-WU8440 LCD Projector
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, one standard ML703 lens, lens
cover, user's manual, security label,
application CD, adapter cover
Optional
Accessories
USBWL11N USB wireless adapter,
TB-1 wireless USB tablet
Optional Lenses 4 optional lenses are available: FL701,
SL702, LL704, UL705
Replacement Parts
Lamp CPWX8240LAMP (DT01281)
Remote Control HL02801
Filter MU06642
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution WUXGA - 1920 x 1200
White Light Output 4,200 ANSI lumens
Color Light Output 4,200 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 16:10 and 4:3 / 16:9 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 3.0 : 1
(with standard lens)
Lens & Operation
Lens x2.0 with motorized zoom, focus and lens shift
Lamp Wattage 245W UHP
Expected Lamp Life* Approximately 2,500 hours (standard mode)
4,000 hours (Eco mode)
Expected Filter Life** Approximately 15,000 hours
Speaker Output 16W (8W x 2)
Acoustic Noise Level 35 dB (29 dB in Eco mode)
Keystone H: +/- 15º and V: +/- 35º
Compatibility
Computer VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA,
WSXGA+, WUXGA, MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 2 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 BNC x 5
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video RCA jack x 3
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port / 100-base-T
Network LAN Wireless IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 375W
Operating Temperature 32ºF - 104ºF (0ºC - 40ºC)
Dimensions (W x D x H) 19.6" x 15.6" x 5.3"
Weight 19.0 lbs
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class A
Warranty 3 year limited parts and labor
Installation
Series
Projection Throw Chart
Screen Size 16:10 Throw Distance
Diagonal Width Min Max
30 24 38 76
60 48 76 151
80 64 101 202
100 80 127 252
150 120 190 377
200 160 253 503
250 200 316 628
300 240 379 754
Throw Ratio: 1.5 - 3.0 : 1 (distance : width)
Screen size and throw distance are measured in inches
with standard lens ML703.
Projection Lens Chart
Lens Inches Meters
ML703 127 - 252 3.2 - 6.4
FL701 69 1.8
SL702 100 - 151 2.5 - 3.8
LL704 240 - 407 6.1 - 10.3
UL705 407 - 691 10.3 - 17.6
Projection distances measured in inches and meters with standard lens
and optional lenses when projecting onto a 100" diagonal screen.
CP-WU8440
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI
•
Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
HI0047-04/12 WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2012 Hitachi America, Ltd. All Rights Reserved .

Hitachi CP-WU8440 Specifications

General

Matrix size	0.76 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	1 - 38.3 m
Projection technology	LCD
Contrast ratio (typical)	300:1
Screen size compatibility	30 - 600 \
Projector native resolution	WUXGA (1920x1200)
Audio input	3
RS-232 ports	1
Connectivity technology	Wired
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	245 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	- h
3D	-
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power	16 W
Number of built-in speakers	2
DVI port	No
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Noise level	- dB
Certification	UL/cUL, FCC Part15 class A, AS/NZS CISPR22 class A, CE, GOST-R
Placement	Ceiling
Product type	Large venue projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 40 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	396 mm
Width	498 mm
Height	135 mm
Weight	8500 g
