Hitachi CP-WU8440 Overview

Hitachi CP-WU8440
4 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #2 background imageLoading...
Page #2 background image
STANDARD FEATURES
CP-WX8255A LCD Projector
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI
Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
HI0150-01/13 WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2013 Hitachi America, Ltd. All Rights Reserved
.
* Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings
and usage. Hours of average filter life specified are not guaranteed and do not constitute part of the product warranty.
** Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user
settings and usage. Hours of average lamp life specified are not guaranteed and do not constitute part of the product or
lamp warranty. Lamp brightness decreases over time.
Installation
Series
UNIQUE FEATURES
Perfect Fit 2
Enables the user to adjust individual corners and sides
independent of one another. Perfect Fit 2 provides vertical
and horizontal digital correction of either barrel or pin
cushion distortions. This feature helps correct geometric and
complicated distortions. Perfect Fit 2 allows the projected image
to fit correctly to the screen quickly and easily.
DICOM
®
Simulation Mode
Images in DICOM (Digital Imaging and Communications in
Medicine) Mode are reproduced with an advanced grayscale
level. This mode is ideal for viewing grayscale medical images
such as X-rays, and for training and educational purposes.
These projectors are not approved medical devices. They
should not be used for actual medical diagnosis.
Center Lens Design
This feature makes it easy to align the projector with the center
of the screen for faster and trouble-free setup.
Drawing Function with Optional Tablet (TB-1)
The optional Hitachi wireless tablet and pen allows you to
engage your audience by annotating over images shown on
the projector.
Multiple Lens Options
In addition to the one ML703 middle throw standard lens,
four optional lenses are available: FL701 fixed; SL702 short
throw; LL704 long throw; and UL705 ultra-long throw.
4
Motorized Zoom, Focus and Lens
Shift Control
Allows for greater range of installation possibilities. With the
motorized function you can make fine adjustments through
the remote control or RS232/IP device.
Display via USB
Simply plug and play using the USB port
instead of the 15-pin D-sub VGA cable.
Network Control, Maintenance and
Security
Embedded networking gives you the ability to manage and
control multiple projectors over your LAN. Features include
scheduling of events, centralized reporting, image transfer and
e-mail alerts for reactive and routine maintenance.
PC-Less Presentation
By using a USB memory stick or other storage device, you
can use the projector without a computer. Menus are easy
to see with a thumbnail display. Additionally there is also a
slideshow function.
PJMessenger
PJMessenger function allows you to send and display text
messages and audio alerts on your networked projectors. It
is an easy and efficient way to send announcements out to
multiple units.
Present Content via LAN
Hitachi’s suite of networking software allows you to easily
send content directly from your PC to the projector via your
LAN connection.
Wireless Presentation Ready
You can use a wireless network by connecting the projector
to a computer using the optional USB wireless adapter part
number USBWL11N. The adapter supports IEEE802.11b/g
and the latest 11n.
Picture By Picture
Hitachi’s picture by picture enables the content from two input
sources to be displayed simultaneously, side by side on one
screen. With such flexibility, the input source can originate from
different locations such as PC x 2 or video x 2, or PC x 1 and
video x 1, with both images sharing equal screen size.
This feature is also ideal for teleconferencing applications.
360º Rotation
Display rotation of 360º for creative applications and greater
installation flexibility.
Status Monitor
With Hitachi’s status monitor, you’ll have
access in real time to projector diagnostics.
Status updates include configuration
information, maintenance history, as well as
error and alarm messaging. For even greater
user convenience, the status monitor can be
accessed on the rear input panel or through
the Hitachi network tools software.

Other manuals for Hitachi CP-WU8440

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hitachi CP-WU8440 and is the answer not in the manual?

Hitachi CP-WU8440 Specifications

General IconGeneral
Matrix size0.76 \
Matrix type3-panel (p-Si TFT active)
Projection distance1 - 38.3 m
Projection technologyLCD
Contrast ratio (typical)300:1
Screen size compatibility30 - 600 \
Projector native resolutionWUXGA (1920x1200)
Audio input3
RS-232 ports1
Connectivity technologyWired
Zoom capabilityYes
Focal length range- mm
Lamp typeUHP
Lamp power245 W
Lamps quantity1 lamp(s)
Light source typeLamp
Service life of light source- h
3D-
Supported video modes1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format systemNTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power16 W
Number of built-in speakers2
DVI portNo
BNC input ports5
USB connector typeUSB Type-A, USB Type-B
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity0
Noise level- dB
CertificationUL/cUL, FCC Part15 class A, AS/NZS CISPR22 class A, CE, GOST-R
PlacementCeiling
Product typeLarge venue projector
Product colorWhite
Cable lock slot typeKensington
Power sourceAC
AC input voltage100 - 240 V
Power consumption (standby)- W
Operating temperature (T-T)0 - 40 °C
Sustainability certificatesRoHS
Weight and Dimensions IconWeight and Dimensions
Depth396 mm
Width498 mm
Height135 mm
Weight8500 g
