Connecting with your devices (continued)
• When
AUTO is selected for the COMPUTER IN1 or COMPUTER IN2 port in
COMPUTER IN of the INPUT menu, that port will accept component video
signals (
38).
•
When the USB TYPE B port and the computer's type A USB port are connected,
you can use the USB TYPE B port as a picture input port from the computer, or use
the remote control as a simple mouse and keyboard of the computer. (
16, 51).
Setting up
(continued on next page)
VCR/DVD/Blu-ray Disc
player
Computer
To Next Page
