Part names
Projector
(1) Lamp cover (94)
The lamp unit is inside.
(2) Speaker (20, 45)
(3) Filter cover (96)
The air lter and intake vent are inside.
(4) Elevator feet (x2) (23)
(5) Elevator buttons (x2) (23)
(6) Remote sensor (17)
(7) Lens (98)
(8) Lens cover
(9) Intake vents
(10) Control panel (5)
(11) FOCUS ring (23)
(12) ZOOM ring (23)
(13) AC IN (AC inlet) (15)
(14) Exhaust vent
(15) Rear panel (5)
►Do not open or remove any portion of the product, unless the
manuals direct it.
►Do not subject the projector to unstable conditions.
►Do not apply a shock or pressure to this product.
►Do not look into the lens and the openings on the projector while the lamp is
on.
WARNING
►Do not touch around the lamp cover and the exhaust
vents during use or just after use, since it is too hot.
►Do not attach anything onto the lens except the lens cover of this
projector because it could damage the lens, such as melting the lens.
CAUTION
(continued on next page)
