Hitachi CP-X4021N - ConGuring the Network Settings Manually

26
Wireless LAN
SSID: WirelessAccessPoint (example)
Encryption: WEP64bit (example)
Encryption key *2:
**********
(example)
Mode: INFRASTRUCTURE
2) Click the [Next].
3) Enter the following information that is set in
the projector. *3
IP address : 192.168.1.10 (example)
Subnet mask: 255.255.255.0 (example)
4) Click the [Connect].
5) The wireless connection will be established.
Proceed to item 1.8 Conrming the connection to your destination. (
30)
1) The setting on the access point. *1
Enter the following information.
*1 Contact the network administrator to nd out the setting on the access point.
*2 If you use an encryption, you need to set it. Contact the network administrator
to check the encryption key that is set in the projector.
The encryption key is always shown as “
**********
”.
*3 To nd the network setting on the projector, refer to the NOTE. (
22)
1.7 Conguring the network settings manually (continued)
1. Connection to the network
