Setting up
Setting up
Install the projector according to the environment
and manner the projector will be used in.
For the case of installation in a special state
such as ceiling mount, the specied mounting
accessories (6SHFLÀFDWLRQV in the 8VHU·VPDQXDO
FRQFLVH) and service may be required. Before
installing the projector, consult your dealer
about your installation.
Arrangement
T-1: CP-X4021N, CP-X5021N (1024X768) (±10%)
Refer to the following tables T-1 and T-2 to determine the screen size and
projection distance. The values shown in the table are calculated for a full size
screen.
Ⓗ×Ⓥ :
Screen size
ⓐ:
Projection distance
(from the projector's end)
ⓑ
,
ⓒ
: Screen height
Projector top
Projector bottom
Screen
type
4:3 16:9
Screen
size
Projection
distance
Screen height
Screen
size
Projection
distance
Screen height
ⒽⓋⓐ min. ⓐ max. ⓑⓒⒽⓋⓐ min. ⓐ max. ⓑⓒ
(inch) m m m inch m inch cm inch cm inch m m m inch m inch cm inch cm inch
30 0.6 0.5 0.9 34 1.5 57 46 18 000.7 0.4 0.9 37 1.6 63 44 17 6 2
40 0.8 0.6 1.2 46 2.0 77 61 24 000.9 0.5 1.3 50 2.1 84 58 23 8 3
50 1.0 0.8 1.5 58 2.5 97 76 30 001.1 0.6 1.6 63 2.7106 73 29 10 4
60 1.2 0.9 1.8 70 3.0117 91 36 001.3 0.7 1.9 76 3.2128 87 34 12 5
70 1.4 1.1 2.1 82 3.5137 107 42 001.5 0.9 2.3 90 3.8150 102 40 15 6
80 1.6 1.2 2.4 94 4.0157 122 48 001.8 1.0 2.6103 4.3171 116 46 17 7
90 1.8 1.4 2.7106 4.5177 137 54 002.0 1.1 2.9 116 4.9193 131 51 19 7
100 2.0 1.5 3.0 118 5.0197 152 60 002.2 1.2 3.3129 5.5215 145 57 21 8
120 2.4 1.8 3.6142 6.0237 183 72 002.7 1.5 3.9155 6.6258 174 69 25 10
150 3.0 2.3 4.5179 7.5297 229 90 003.3 1.9 5.0195 8.2323 218 86 31 12
200 4.1 3.0 6.1239 10.1396 305120 004.4 2.5 6.6261 11.0 432 291 114 42 16
250 5.1 3.8 7.6300 12.6496 381150 005.5 3.1 8.3327 13.7 541 363 143 52 20
300 6.1 4.6 9.1360 15.1596 457180 006.6 3.7
10.0
39316.5650 436 172 62 25
