Hitachi CP-X505 - Easy Menu

24
EASY Menu
EASY Menu
Item Description
ASPECT
Using the ◄/► buttons switches the mode for aspect ratio.
See the ASPECT item in IMAGE menu (

29).
AUTO
KEYSTONE
EXECUTE
Using the ► button executes the auto keystone function.
See the AUTO KEYSTONE EXECUTE item in SETUP menu (

35).
KEYSTONE
Using the ◄/► buttons corrects the vertical keystone distortion.
See the KEYSTONE item in SETUP menu (

35).
KEYSTONE
Using the ◄/► buttons corrects the horizontal keystone distortion.
See the KEYSTONE item in SETUP menu (

35).
PICTURE MODE
Using the ◄/► buttons switches the picture mode.
The picture modes are combinations of GAMMA and COLOR
TEMP settings. Choose a suitable mode according to the projected
source.
NORMAL
ó
CINEMA
ó
DYNAMIC
WHITEBOARD
ó
BOARD(GREEN)
ó
BOARD(BLACK)
COLOR TEMP GAMMA
NORMAL MID DEFAULT #1 DEFAULT
CINEMA LOW DEFAULT #2 DEFAULT
DYNAMIC HIGH DEFAULT #3 DEFAULT
BOARD(BLACK) Hi-BRIGHT-1 DEFAULT #4 DEFAULT
BOARD(GREEN) Hi-BRIGHT-2 DEFAULT #4 DEFAULT
WHITEBOARD MID DEFAULT #5 DEFAULT
• When the combination of GAMMA and COLOR TEMP differs
from pre-assigned modes above, the display on the menu for the
PICTURE MODE is “CUSTOM”. Please refer to the GAMMA (

26)
and COLOR TEMP (

27) items in PICTURE menu.
• When this function is performed, a certain extra such as a line may appear.
From the EASY MENU, items shown in the table below can
be performed.
Select an item using the ▲/▼ cursor buttons on the
projector or remote control. Then perform it according to the
following table.
'#5;/'07=4)$?
#52'%6



':'%76'




)QVQ#FXCPEGF/GPW

014/#.
014/#.
014/#.
J
'0).+5*
#761-';5610'
-';5610'
-';5610'
2+%674'/1&'
$4+)*60'55
%1064#56
%1.14
6+06
5*#420'55
9*+52'4
/+4414
4'5'6
(+.6'46+/'
.#0)7#)'

(continued on next page)
