Hitachi CP-X8160 Brochure & Specs

Specifications
Projection Technology
3LCD, 3 chip technology
Number of Pixels
786,432 pixels
Resolution
Video
540 TV lines
Computer
1024 dots x 768 lines
Colors
16.7 million colors
Aspect Ratio
Native 4:3/16:9 and 16:10 compatible
Lens
F = 2.0 mm with motorized zoom, focus and lens shift
Throw Ratio (distance : width)
1.5 - 3.0:1
Lamp
330W
White Light Output
6,000 ANSI lumens
Color Light Output
6,000 ANSI lumens
Expected Lamp Life
Approximately 2,500 hours (standard mode),
3,000 hours (Eco mode)***
Contrast Ratio
3000 : 1 (using active IRIS)
Speaker Output
16W (8W+8W) stereo
Power Supply
AC90 - 132V / AC198 - 264V (50/60 Hz)
Power Consumption
AC100 - 120V, 50/60 Hz, 480W; AC220 - 240V, 50/60 HZ, 455W
Operating Temperature
32˚F - 113˚F (0˚C - 35˚C)
Input Signals
Computer
VGA, SVGA, XGA, WXGA, WXGA+, SXGA, WSXGA+, UXGA, MAC16"
Composite Video
NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video
480i, 480p, 576i, 720p, 1080i, 1080p
HDMI
480i, 480p, 576i, 720p,1080i, 1080p,
computer signal — TMDS clock 27 MHz to 150 MHz
Acoustic Noise Level
37 dB (31 dB in Eco mode)
H-Sync
31.5 kHz - 106 kHz
V-Sync
56 Hz - 120 Hz
Horizontal and Vertical Keystone
+/- 35º with standard lens
Approvals
UL60950-1, C-UL, FCC part 15 subpart B Class A
Computer Input
Analog Computer 1
15 pin D-sub x 1
Analog Computer 2
BNC x 5
Computer Monitor Output
15 pin D-sub x 1
Digital Input
HDMI x 2
Video Input
S-Video
Mini DIN 4-pin connector x 1
Composite Video
RCA jack x 1
Component Video
RCA jack x 3,15 pin D-sub x 1 (shared with computer In 1)
BNC x 3 (shared with computer In 2)
USB Input
USB type A x 2 (for optional wireless network or TB-1 pen tablet)
USB type B x 1 (for USB display or mouse control)
Audio
Input
3.5 mm stereo mini jack x 2, RCA jack (L,R) x 1
Output
RCA (L/R) x 1
Network (LAN)
RJ-45 x1 (wired LAN)
Control Terminals
9 pin D-sub x1 for RS-232C (serial)
Dimensions (W x D x H)
19.6" x 15.6" x 5.3"
Weight
19.18 lbs.
Closed Captioning
CC1, CC2, CC3, CC4, T1, T2, T3, T4
Supplied Accessories
Remote control with two AA batteries, power cord, computer
cable, one standard ML703 lens, lens cap, user’s manuals,
security label, application software (CD x 1), wireless USB cover
Optional Accessories
TB-1 wireless USB tablet, H02851 laser remote, USBWL11N
USB wireless adapter
Optional Lenses
4 optional lenses are available: FL701, LL704, SL702, UL705
Replacement Parts
Lamp
CPWX8255LAMP (DT01291)
Remote Control
HL02801
Filter
MU06642
1.800.HITACHI
900 Hitachi Way, Chula Vista, CA 91914
hitachi-america.us/projectors
*** Actual lamp life will vary by individual lamp and based on environmental conditions, selected
operating mode, user settings and usage. Hours of average lamp life specified are not guaranteed and
do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
HI0028-02/12-WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2012 Hitachi America, Ltd. All Rights Reserved.
Complete Specifications: CP-X8160
Projection Throw Chart
Find Hitachi Projectors
on Facebook
Follow us on Twitter
@HALprojectors
Hitachi Projectors
are on YouTube
Installation
Series
Screen Size* Throw Distance*
Diagonal* Width* Min* Max*
30 24 37 73
60 48 73 146
80 64 98 194
100 80 122 242
150 120 183 363
200 160 244 484
250 200 305 605
300 240 366 725
Screen Size 4:3 Throw Distance
Throw Ratio: 1.5 - 3.0 : 1 (distance : width)
*Measured in inches with standard lens ML703
Input/Output Terminals
HDMI
Component
Remote Control
Kensington Lock
Remote Sensor
USB Type A
S-Video
USB Type BLANStatus Monitor
Control (RS-232C)
AC Inlet
Audio In 1
Audio In 3
Audio In 2
Composite Video
Computer In 1
Computer In 2
Audio Out
HDMI
AMX Device Discovery
Hitachi Trade-Up Program
Crestron Integrated Partner
3 Year Warranty
Closed Captioning
3LCD Technology
Projector Lens Chart
Lens Inches** Meters**
ML703
(Standard Lens)
122 - 242 3.1 - 6.2
FL701
66 1.7
SL702
97 - 145 2.5 - 3.7
LL704
231 - 392 5.9 - 10.0
UL705
393 - 667 10.0 - 16.9
** Projection distances for standard lens and optional
lenses when projecting onto a 100" diagonal screen.
Security Bar
Monitor Out

Hitachi CP-X8160 Specifications

General

Matrix size	0.8 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	0.9 - 36.8 m
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	30 - 600 \
Projector native resolution	XGA (1024x768)
Audio input	3
RS-232 ports	1
Connectivity technology	Wired
Zoom capability	Yes
Focal length range	- mm
Lamp type	UHP
Lamp power	330 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	- h
3D	-
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL 60, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1360 x 768 (WXGA), 1400 x 1050 (SXGA+), 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power	16 W
Number of built-in speakers	2
BNC input ports	5
USB connector type	USB Type-A, USB Type-B
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Noise level	- dB
Certification	UL/cUL, FCC Part15 class A, AS/NZS CISPR22 class A, CE, GOST-R
Placement	Ceiling
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
Power consumption (standby)	- W
Operating temperature (T-T)	0 - 45 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	396 mm
Width	498 mm
Height	135 mm
Weight	8700 g
