Hitachi CS 33EA - Page 21

PART
S
CS 33EA
DESCRIPTION REMARKS
1 668-5078 CIRCLIP 2
2 668-5079 PISTON PIN 1
3 668-5080 PISTON SET 1 INCLUD. 1,4
4 668-5081 PISTON RING 2
5 668-5082 SCAVENGING COVER (B) 1
6 668-5083 CYLINDER PACKING 1
7 668-5084 CYLINDER SET 1 INCLUD. 6
8 668-4668 HEX. HOLE BOLT M5X20/S 4
* 9 668-5085 SPARK PLUG BPM6A 1 FOR USA
* 9 668-5086 SPARK PLUG BPMR6A 1 FOR EUROPE, AUS
10 668-5087 SPARK PLUG CAP ASS'Y 1
11 668-5088 HIGH VOLTAGE CORD 1
12 668-5089 IGNITION COIL COMP. 1
13 668-4602 RUBBER CAP 1
14 668-5091 IGNITION COIL ASS'Y 1 INCLUD. 11-13
15 668-5092 COVER PACKING (A) 2
16 668-5093 HEX. SOCKET HD. BOLT M4X10 4
17 668-5094 SCAVENGING COVER (A) 1
18 668-4600 WASHER 2
19 668-4599 HEX. HOLE BOLT M4X18/WS 2
20 668-4607 OIL SEAL TB 12227 2
21 668-5095 NEEDLE ROLLER 2.5X9.8 2
22 668-5096 BALL BEARING 6201 A2C3 2
23 668-5097 CRANK SHAFT COMP. 1
24 668-4899 WOODRUFF KEY 3X13X4.5 1
25 668-5098 SHIM S T0.2 1
25 668-5099 SHIM S T0.3 1
26 668-5100 CRANK CASE PACKING 1
27 668-4668 HEX. HOLE BOLT M5X20/S 3
28 668-5101 D4E RETAINING RING 2
29 668-5102 MAGNETO ROTOR ASS'Y 1 INCLUD. 28, 32, 33
30 668-5103 BOLT WASHER M7 1
31 668-5104 FLYWHEEL NUT 1
32 668-5105 STARTER PAWL SPRING 2
33 668-5106 STARTER PAWL 2
34 668-5107 CRANK CASE ASS'Y 1 INCLUD. 20-22, 26
* 35 986-662 MACHINE SCREW (W/WASHERS) M4X10 4 FOR EUROPE, USA
* 35 668-5109 MACHINE SCREW (W/SP. WASHER) M4X8 4 FOR AUS, RUS
36 668-5110 EXHAUST PIPE 1
37 668-5111 MUFFLER SPECIAL PACKING 1
* 38 668-5112 GAUZE FIXING PLATE 1 EXCEPT FOR AUS, RUS
* 39 668-5113 MUFFLER GAUZE 1 EXCEPT FOR AUS, RUS
40 668-5114 HEX. SOCKET HD. BOLT M5X50 2
41 668-4661 WASHER 5 2
* 42 668-5115 MUFFLER COMP. 1 FOR EUROPE, USA
* 42 668-5116 MUFFLER COMP. 1 FOR AUS, RUS
43 668-5117 MUFFLER PACKING 1
71 668-5119 BRAKE SUPPORT PLATE COMP. 1
72 668-5120 COLLAR 1
73 668-5121 BRAKE LINK COMP. 1
- 4 - 3 - 09
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
