Hitachi CS 33EA - Page 22

PART
S
CS 33EA
DESCRIPTION REMARKS
74 668-5122 BRAKE LEVER SPRING 1
75 668-5264 BRAKE HANDLE 1
76 CAUTION LABEL 1
77 668-5126 BRAKE LINK COVER 1
78 668-5127 OIL ADJUST GROMMET 1
79 668-5128 OIL PUMP ADJUSTER 1
80 668-5129 ADJUSTER SPRING 1
81 668-5070 BOLT WASHER M4 1
82 668-5130 OIL PUMP ADJUST CAP 1
83 668-5131 PUMP GEAR SPRING 1
84 668-5132 PUMP GEAR COMP. 1
85 668-5133 MACHINE SCREW M3X8 1
86 668-5134 OIL PUMP CASE COMP. 1
87 668-5135 OIL PUMP CASE ASS'Y 1 INCLUD. 79-86
88 668-5136 SEAL LOCK BOLT M5X15 5
89 668-5267 FUEL PIPE 2.5X4X90 1
90 668-5139 PRIMING PUMP COMP. 1
91 668-5140 BRAKE BAND 1
92 668-5141 NEEDLE ROLLER 3X9.8 1
93 668-5142 CLUTCH COMP. 1
94 668-5143 NEEDLE BEARING 1
95 668-5144 CLUTCH HOUSING COMP. 1
96 668-5145 CLUTCH WASHER 1
97 668-5146 CRANK SHAFT COLLAR 1
98 668-5147 OIL PUMP COVER 1
99 668-5148 TAPPING SCREW D4X15 3
100 668-5149 MACHINE SCREW (W/SP. WASHER) M4X14 2
101 668-5150 OIL PIPE (A) 1
102 668-5151 SCREW GEAR 1
103 668-5152 TAPPING SCREW D4.5X14 3
104 668-5153 TAPPING SCREW D4.5X14 3
105 668-5154 FUEL PIPE 1
106 668-5155 CHAIN CATCHER 1
107 668-5156 AIR VENT SPONGE 1
108 668-5157 GUIDE PLATE (B) 1
109 668-5158 TAPPING SCREW D3X8 1
* 110 668-5294 CHAIN BAR 12 INCH 3/8 SP 1 FOR EUROPE, USA
* 110 668-5295 CHAIN BAR 14 INCH 3/8 SP 1 FOR EUROPE, AUS, USA
111 668-5161 TAPPING SCREW D4X10 1
112 668-5162 GUIDE PLATE (A) 1
113 NAME PLATE (CS 33EA) 1
114 668-5165 SIDE COVER COMP. 1
115 668-5166 NUT 2
116 668-5167 BRAKE SPRING 1
117 668-5168 GEAR (A) 1
118 668-5169 CHAIN PULLER COMP. 1
* 119 668-5170 SAW CHAIN (3/8X12") 91VG-45 1 FOR EUROPE, USA
* 119 668-5171 SAW CHAIN (3/8X14") 91VG-52 1 FOR EUROPE, AUS, USA
120 668-5161 TAPPING SCREW D4X10 1
121 668-5270 SPIKE 1
3 - 09 - 5 -
*ALTERNATIVE PARTS
NO.
USED
CODE NO.
ITEM
NO.
