Hitachi CS 33EDT Handling Instructions

113
ITEM NO. PART NAME Q’TY
1 AIR CLEANER BASE 1
2 HEX. SOCKET HD. BOLT M5×45 2
3 CLEANER SPONGE (B) 1
4 CLEANER ELEMENT A COMP. 1
5 CLEANER ELEMENT B COMP. 1
6 CLEANER SPONGE (A) 1
7 CLEANER COVER 1
8 CLEANER KNOB 1
9 TAPPING SCREW (W/FLANGE) D4×16 13
10 MUFFLER COVER 1
11 CLUTCH 1
12 CLUTCH HOUSING 1
13 NEEDLE BEARING (D) 1
14 CLUTCH WASHER 1
15 CRANK SHAFT COLLAR 1
16 OIL PUMP COVER 1
17 NEEDLE ROLLER 2.5×19.8 2
18 PUMP GEAR 1
19 PUMP GEAR SPRING 1
20A PUMP CASE 1
21A PUMP ASS’Y (INCLUD.17-20) 1
22 SEAL LOCK BOLT M5×15 5
23 INTAKE PACKING 1
24 INTAKE 1
25A HEX.SOCKET BOLT M4 2
26 PULSE GUIDE 1
27 ENGINE CASE COVER 1
28 CLEANER BODY 1
30 CARBURETOR ASS’Y (INCLUD.32-47) 1
31 INLET SPACER 1
32 SCREW 1
33 PUMP BODY 1
34 PUMP GASKET 1
35 PUMP DIAPHRAGM 1
36 INLET SCREEN 1
37 NEEDLE VALVE 1
38 VALVE SPRING 1
39 CONTROL LEVER 1
40 IDLE ADJUST SPRING 1
41 IDLE ADJUST SCREW 1
42 HINGE PIN SET SCREW 1
43 HINGE PIN 1
44 DIAPHRAGM PACKING-METERING 1
45 METERING DIAPHRAGM 1
46 DIAPHRAGM COVER-METERING 1
47 SET SCREW 4
48 IDOL SPONGE 1
49 CHOKE LEVER 1
50 PROTECTIVE COIL 1
51 FUEL PIPE 2.5×4×47 1
52 PRIMING PUMP COMP. 1
53 AIR VENT SPONGE 1
54 AIR VENT VALVE (B) 1
55 OIL PIPE 1
56 PIPE JOINT 1
57 FLANGED TAPPING SCREW D5×15 1
58 CHAIN CATCHER 1
59A ENGINE CASE ASS’Y (INCLUD.54,90) 1
60 MACHINE SCREW (W/WASHERS) M4×12 3
61 EXHAUST PIPE 1
62 MUFFLER SPECIAL PACKING 1
63 GAUZE FIXING PLATE 1
64 MUFFLER GAUZE 1
65 MUFFLER 1
66 MUFFLER PACKING 1
67 HEX. SOCKET HD. BOLT M4×10 6
68 SCAVENGING COVER (B) 1
70 HEX. SOCKET HD. BOLT M6×55 2
71 BOLT WASHER M6 6
72 CRANK WORM ASS’Y (INCLUD.73-76) 1
73 WORM 1
74 OIL SEAL 2
75 BALL BEARING 2
76 CRANK SHAFT 1
77 CRANK CASE 1
78 HEX. SOCKET HD. BOLT (W/SP.WASHER) M5×18 4
79 CIRCLIP 2
80 PISTON (M) 1
81 PISTON RING (XR1-1856) 1
82 PISTON PIN 1
83 BOLT WASHER M7 1
84 FLYWHEEL NUT 1
ITEM NO. PART NAME Q’TY
85 RETAINING RING D4 2
86 MAGNETO ROTOR COMP. 1
87 STARTER PAWL SPRING 2
88 STARTER PAWL 2
89 MAGNETO ROTOR ASS’Y (INCLUD.85-88) 1
90A INNER CAP 1
91 TANK CAP PACKING 2
92 FUEL TANK CAP ASS’Y (VERMILION) (INCLUD.91) 1
93 CYLINDER 1
94 SPARK PLUG BPMR7A 1
95 IGNITION COIL 1
96 GLASS WASHER 2
98 SCAVENGING COVER (A) 1
99 METAL FITTING OF PLUG CAP (A) 1
100 CORD (A) 1
101 SPARK PLUG CAP 1
102 CORD (B) 1
103 HEX. SOCKET HD. BOLT (W/WASHERS) M4×18 2
104 WASHER M5 (BLACK) 2
105 CAUTION LABEL (HOT) 2
106 GROMMET 3
107 PROTECTION SHEET 2
108 PACKING PLATE 1
109 MUFFLER SPECIAL PACKING (S) 1
110 WOODRUFF KEY 3×13×4.5 1
111 CORD INSULATION TUBE 2
112 FUEL TANK CAP ASS’Y (BLACK) (INCLUD.91) 1
121 TAPPING SCREW D5×40 1
122 WASHER 1.0 1
123 COLLAR 28.2 1
124 DAMPER 1
125 REAR HANDLE (B) 1
126 TRIGGER LOCKOUT 1
127 THROTTLE WIRE 1
128 STOP SWITCH 1
129 NUT M6 2
130 THROTTLE LEVER SPRING 1
131 THROTTLE LEVER 1
132 SPRING HOLDER 2
133 DAMPER SET BOLT 2
134 ANTIVIBRATION SPRING 2
135 NAME PLATE 1
136 FLANGE NUT M8 1
137 SIDE CASE (VERMILION) 1
138 BRAKE SUPPORT PLATE 1
139 BRAKE LEVER SPRING 1
140 BRAKE LINK 1
141 BRAKE BAND 1
142 NEEDLE ROLLER D3 1
143 BRAKE SPRING 1
144A CHAIN PULLER 1
145 GUIDE PLATE (B) 1
146 TAPPING SCREW D3 1
147 TAPPING SCREW D4×10 1
148A SAW CHAIN 1
149 CHAIN BAR 1
150 FUEL PIPE 1
151 SPIKE SET 1
152 FUEL PIPE (FKM) L240 1
154 FUEL PIPE (FKM) L260 1
155 FUEL GROMMET 1
156 REAR HANDLE (A) 1
157 TAPPING SCREW (W/FLANGE) D5×16 2
158A FRONT HANDLE 1
159 BRAKE HANDLE 1
160 CAUTION LABEL 1
161 BRAKE LINK COVER 1
162 PUMP FILTER BODY 1
163 CLIP 2
164 OIL FILTER BODY 1
165 OIL FILTER 1
166 BOLT WASHER D5 1
167 AIR DEFLECTOR 1
168A RECOIL STARTER (VERMILION) 1
169 TAPPING SCREW (W/FLANGE) D4×20 8
170 HITACHI LABEL 1
171 CORD INSULATION TUBE 1
172 SPRING COVER 1
173 FUEL GROMMET (A) 1
501 CHAIN COVER 1
502 COMBI BOX SPANNER 13×19 1
