15
NOTES :
• When the "ANTI-SHOCK" is operating, the battery consumption is higher
because the disc rotates faster than normal and also the memory circuitry is
activated.
• When the digital anti-shock function is switched "ON" or "OFF", the sound is
interrupted for a short time. This is normal.
• Remember that condition such as dirty, scratched or warped discs may cause
skipping or noise thereby affecting performance of "ANTI-SHOCK" system.
PRODUCT SPECIFICATIONS
PICK UP
System Compact disc digital audio system
Laser diode Material : GaAlAs
Properties Wavelength: λ = 780nm
Emission duration : continuous
Laser output: < 44.6µW
Error correction Cross-interleave Reed-solomon code
AUDIO
D/A conversion DAC four times oversampling
Frequency response 20-20,000Hz (+1/-3 dB)
Wow and filter Below measurable limits
No. of channels 2 Channel (stereo)
Output level Phones : 20mW (32Ω)
Bass boost effect (100Hz) +8 dB
GENERAL
Power requirements - 2 x LR6 "AA" alkaline battery
- DC in 6V jack accepts AC power adaptor
(centre positive)
Power consumption 0.8W (DC 3V) under normal condition
Dimension Approx. 128 (W) x 28.5 (H) x 137 (D) mm
Weight Approx. 200g not including battery
