-3-
+
Effective length
Overall length
2. Optional Accessories
(1) Drilling anchor holes (rotation and hammering)
Drill bit (SDS-plus shank)
Outer dia.
(mm)
Overall
length
(mm)
Effective
length
(mm)
Code No.
Outer dia.
(mm)
Overall
length
(mm)
Effective
length
(mm)
Code No.
4.0 303571 12.5 166 100 303592
4.3 303572 12.5 260 200 303607
4.5 303573 12.7 166 100 303593
4.8 303574 12.7 260 200 303608
5.0
110 50
303575 13.0 303594
5.0 160 100 303578 14.0 303595
5.5 303576 14.3
166 100
303596
6.0
110 50
303577 14.3 260 200 303609
6.0 303579 14.5 166 100 303597
6.4 303580 14.5 260 200 303610
6.5 303581 15.0 303598
7.0 303582 16.0
166 100
303599
7.5 303583 16.0 260 200 303611
8.0 303584 16.5 303600
8.5 303585 17.0
166 100
303601
9.0 303586 17.0 260 200 308485
9.5 303587 17.5 166 100 303602
10.0
160 100
303588 17.5 260 200 303612
10.0 260 200 303604 18.0 166 100 303603
10.5 160 100 303589 19.0 260 200 303613
10.5 260 200 303605 20.0 303614
11.0 160 100 303590 22.0
250 200
303615
12.0 166 100 303591
12.0 260 200 303606
To Next Page
