(1) Drill bit (slender shaft)
(2) Adapter for slender shaft
(SDS-plus shank)
(1) Drill bit (taper shank) (2) Taper shaft adapter
(SDS-plus shank)
(3) Cotter
++
++
Straight-shank bit for
impact drills
Rubber cap
13-mm hammer drill chuck
(SDS-plus shank)
Chuck wrench
Slender bit and adapter for slender shaft (SDS-plus shank)
(1) Drill bit (slender shaft) (2) Adapter for slender shaft
Outer dia.
(mm)
Overall length
(mm)
Effective length
(mm)
Code No. Code No.
3.4 306369
3.5
90 45
306368
306370
Drill bit (taper shank)
(1) Drill bit (taper shank) (2) Taper shank adapter (3) Cotter
Outer dia. (mm) Code No. Type Code No. Code No.
1100
12.3
12.7
14.3
14.5
17.5
944460
944461
993038
944462
944500
944463
Morse taper No. 1 303617 944477
13-mm hammer drill chuck
Part name Code No.
13-mm hammer drill chuck (including chuck wrench and rubber cap) 303332
Chuck wrench 303334
Rubber cap 303335
