-6-
Cold chisel
(SDS-plus shank)
Code No. 316657
Cutter
(SDS-plus shank)
Code No. 316658
Grooving chisel
(SDS-plus shank)
Code No. 316659
+
+
+
Special screw Chuck adapter (G)
(SDS-plus shank)
Chuck wrench
13-mm drill chuck
(13VLRB-D)
++
NOTE:
To use the tool for tightening or loosening screws,
open the three jaws of the drill chuck and securely
fix the drill chuck to chuck adapter (G) with the
special screw (a left-hand threaded M6 screw) when
mounting the drill chuck onto chuck adapter (G).
+
Stamped bit No.
Tip thickness
(5) Drilling holes and driving screws (rotation only)
Part name Code No.
Chuck adapter (G) 303623
13-mm drill chuck (with chuck wrench) 321814
Special screw (M6 left-hand threaded) 981122
(1) Cross-recessed head (Phillips) bit (2) Slotted-head (minus) bit
[Overall length: 65 mm] [Overall length: 70 mm]
(For use with cross-recessed head (Phillips) screw)) (For use with slotted-head (minus) screw))
Bit No. Code No. Applicable screw dia. (mm) Bit tip thickness Code No.
Applicable screw
dia. (mm)
No. 2 983006 3 to 5 0.8 955659 4
No. 3 983011 6 to 8 * 1 955674 5 to 6
* Temporary tightening
