x Wiring of the DC-Speed Control Switch
Positive (+) terminal Red marking
Negative (-) terminal
Internal wire (red)
from
Controller (B) [36]
Internal wire (white) Internal wire (red)
Internal Wire (Black) [31]
Internal wire (red)
from
Controller (B) [36]
Internal wire (white)
from
Controller (B) [36]
Internal Wire (Red) [30]
x Motor polarities
