Air End
Discharge Air pipe
Air End
Discharge Air pipe
Intercooler Header
Aftercooler Header
Rotating Parts!
●Keep hands and rods, etc. away from
the rotating parts (Cooling fans, etc.)
●Use caution at all times, when air com-
pressor is powered. The air compres-
sor may be capable of restarting with-
out hitting the START button.
●When the air compressor is operating,
do not remove or open the enclosure
panels and doors.
●Before servicing the air compressor,
stop it, disconnect the power, especially
when accessing any rotating parts.
WARNING
WARNING
WARNING
Hot Surface!
●Do not directly touch any component
inside the air compressor enclosure
when the air compressor is operating
or immediately after it has stopped,
as the components are extremely hot
and can cause severe injury.
●Before servicing the air compressor,
stop it, disconnect the power, then
wait for the air compressor to cool
down.
Heated!!
Hot Surface!
●Do not directly touch any component
inside the air compressor enclosure
when the air compressor is operating
or immediately after it has stopped,
as the components are extremely hot
and can cause severe injury.
●Before servicing the air compressor,
stop it, disconnect the power, then
wait for the air compressor to cool
down.
Heated!!
WARNING
Electric Shock Hazard!
●Before servicing or wiring the
air compressor, disconnect
the power. This will prevent
anyone from turning on the
power and causing an elec-
tric shock that could lead to
severe injury or death.
●Do not allow any unlicensed
person to wire the air compres-
sor. Always use a licensed
electrician.
●Ground the air compressor.
WARNING
Electric Shock Hazard!
●Before servicing or wiring the
air compressor, disconnect
the power. This will prevent
anyone from turning on the
power and causing an elec-
tric shock that could lead to
severe injury or death.
●Do not allow any unlicensed
person to wire the air compres-
sor. Always use a licensed
electrician.
●Ground the air compressor.
To ensure safe and proper operation of the air compressor, it is indispensable to carefully
read and understand the following warnings and instructions detailed below. These warn-
ings and instructions are attached to the air compressor as shown in the figure below.
2
1. SAFETY
