6
2. GENERAL DESCRIPTION [Components]
2.2 Components
Ventilating Fan
Check Valve
Intercooler
Aftercooler
Oil Filter
Air Intake Filter
1st-Stage Air end
2nd-Stage Air end
Main Motor
Oil Mist Remover
Discharge Pipe
(Compressed Air Discharge)
Oil Level Gauge
Common Base
Starter /
Control Box
Safety Relief Valve
Enclosure
Instrument Panel
Gear Case
Oil Filling Port
Oil Pump
Oil Cooler
Intercooler
Blow-off air cooler
