SPECIFICATIONS
POWER TOOL
Model DV14DCL2 DV18DCL2
No-load speed (Low/High) 0 400 / 0 1500 min
-1
0 400 / 0 1500 min
-1
No-load impact rate (Low/High) 0 5600 / 0 21000 min
-1
0 5600 / 0 21000 min
-1
Capacity
Drilling
Brick
(Depth 30 mm)
13 mm 13 mm
Wood
(Thickness 18 mm)
32 mm 38 mm
Metal
(Thickness 1.6 mm)
13 mm 13 mm
Driving
Machine screw 6 mm 6 mm
Wood screw
8 mm (diameter) × 50 mm (length)
(Requires a pilot hole)
8 mm (diameter) × 75 mm (length)
(Requires a pilot hole)
Rechargeable battery BCL1415: Li-ion 14.4 V (1.5 Ah
4 cells)
BCL1815: Li-ion 18 V (1.5 Ah 5 cells)
Weight 1.5 kg 1.6 kg
CHARGER
Model UC18YKL
Charging voltage 7.2 18 V
Weight 0.4 kg
STANDARD ACCESSORIES
In addition to the main unit (1), the package contains the
accessories listed in the table below.
DV14DCL2
DV18DCL2
1 Plus driver bit (No. 2 × 65L) ....................1
2 Charger ..................................................1
3 Plastic case ............................................ 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
1. Battery (BCL1415)
(For DV14DCL2)
2. Battery (BCL1815)
(For DV18DCL2)
Optional accessories are subject to change without notice.
APPLICATIONS
Drilling of brick and concrete block, etc.
Driving and removing of machine screws, wood screws,
tapping screws, etc.
Drilling of various metals.
Drilling of various woods.
BATTERY REMOVAL/INSTALLATION
1. Battery removal
Hold the handle tightly and push the battery latch (2 pcs.)
to remove the battery (see Figs. 1 and 2).
CAUTION
Never short-circuit the battery.
2. Battery installation
Insert the battery while observing its polarities (see
Fig. 2).
CHARGING
Before using the power tool, charge the battery as follows.
1. Connect the charger’s power cord to the receptacle.
When connecting the plug of the charger to
a receptacle, the pilot lamp will blink in red
(At 1-second intervals).
2. Insert the battery into the charger.
Firmly insert the battery into the
charger till it contacts
the bottom of the charger and checking the polarities as
shown in Fig. 3.
CAUTION
If the batteries are inserted in the reverse direction, not
only recharging will become impossible, but it may also
cause problems in the charger such as a deformed
recharging terminal.
3. Charging
When inserting a battery in the charger, the pilot lamp will
light up continuously in red.
When the battery becomes fully recharged, the
pilot lamp will blink in red (At 1-second intervals).
(See Table 1)
(1) Pilot lamp indication
The indications of the pilot lamp will be as shown in
Table
1, according to the condition of the charger or the
rechargeable battery.
000BookDV14DCL2.indb7000BookDV14DCL2.indb7 2012/02/298:46:552012/02/298:46:55
