8-3. Lubrication
(1) Apply ATTOLUB MS No. 2 (Code No. 309922) to the following.
Holder [13]: Ratchet ••••••••••••••••••••••••••••••••••• 1g
Gear [8]: Teeth •••••••••••••••••••••••••••••••••••••• 2g
Ratchet ••••••••••••••••••••••••••••••••••• 0.5 g
Spindle [4]: Needle bearing contacting portion ••• 1g
Ball chamber ••••••••••••••••••••••••••••• 0.5 g
Armature [15]: Pinion ••••••••••••••••••••••••••••••••••••• 1g
8-4. Tightening Torque
Drill Chuck [3] ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 29.4 to 39.2 N
m (300 to 400 kgf
cm)
Tapping Screw (W/Flange) D4 x 20 [20]
Tapping Screw (W/Flange) D4 x 16 [32]
••••••••••••••••••••••••• 2.5 to 3.0 N
m (25 to 30 kgf
cm)
