Hitachi FDV 16VB2 Technical Data And Service Manual

--- 3 ---
Bearings
Maker
Dimensions
Model
HITACHI
FDV 16VB2
FDV 16VB
289 mm (11-3/8")
198 mm (7-7/8")
67 mm (2-5/8")
1.6 kg (3.5 lbs.)
Length
Width
Height
(4) Lightweight and compact
Weight
287 mm (11-3/8")
192 mm (7-5/8")
67 mm (2-5/8")
1.6 kg (3.5 lbs.)
299 mm (11-3/4")
211 mm (8-3/8")
66 mm (2-5/8")
1.7 kg (3.7 lbs.)
(5) Easy to operate 2-finger sized trigger switch with variable speed control dial
The pulling amount of the trigger can be adjusted on the dial in the same manner as the Model FDV 16VB. It
is convenient for operation keeping at desired speed. The large variable speed control dial and the 2-finger
sized trigger switch are easy to operate.
(6) Easy-to-operate push-button type forward/reverse changeover switch
The Model FDV 16VB2 is equipped with the push-button type forward/reverse changeover switch that is more
convenient and reliable than the lever-type switch. In addition, this switch is properly shaped and located not
to make the pushing button an obstruction at drilling.
C-1, C-2

Hitachi FDV 16VB2 Specifications

General

Brand	Hitachi
Model	FDV 16VB2
Category	Drill
Language	English
