English - 23 -
GENERAL CHARACTERISTICS
Supply Voltage 220 - 240 V AC ~ 50Hz
Input Frequency 470Mhz-862Mhz
Maximum Power consumption 18 W
Standby Power Consumption 1 W
Operating temperature 5ºC to +45ºC
Storage temperature -15ºC to +55ºC
Humidity 25 to 75 % rel
Physical dimensions 360x280x48 mm
Weight 2820 g
HARDWARE CONFIGURATION
Main Processor STM5100
Flash Memory 8 MB
DDRRAM 64 MB
DIGITAL CAPABILITIES
Transmission Standards DVB, MPEG2
DEMODULATION
COFDM with 2K/8K FFT mode.
FEC for all DVB Modes.(Automatically found)
VIDEO
ALL MPEG-2 MP@ML Video Decoder
Aspect Ratio 4:3, 16:9 with pan vector
RGB analogue outputs. BW ≥ 5MHz at 0.5 to 5 MHz sweep signal
CVBS analogue output.
AUDIO
MPEG1 Layer 1 and 2
Sampling frequencies supported 32 kHz, 44.1 kHz or 48 kHz.
Output can be programmed as STEREO, LEFT only or RIGHT only (on both outputs). This is useful for dual
mono channels in order to select the correct sound track, which is stored for every channel.
Wide dynamic range 16-bit resolution
REMOTE CONTROL
Operating Distance 10 m Max.
Batteries 2x1.5V Micro (R-03/AAA)
