Hitachi L26A01 - Page 32

...or through a s atellite decoder...
...or through a VCR and satellite decoder.
ANT.IN
ANT.IN
ANT.IN
RF Lead to Aerial
RF Lead to
Aerial
RF Lead
from VCR to
Satellite
RF Lead from
VCR to TV
Satellite LNB lead
Satellite LNB lead
RF Lead from
Satellite to TV
Aerial
Aerial
VCR
• Scart Lead to
AV on TV.-1
• Scart Lead to
AV-1 on TV.
AV-1
TV
TV
VCR
VCR
AV-2
TFT -LCD TV
TFT -LCD TV
