— 8 —
English
SPECIFICATIONS
Operating pressure 70 – 120 psi (4.9 – 8.3 bar 5 – 8.5 kgf/cm
2
)
Dimensions 21-3/16" × 13-3/8" × 4-1/4"
Length × Height × Width (538 mm × 340 mm × 108 mm)
Weight 7.9 lbs (3.6 kg)
Nail capacity 64 – 70 nails (2 strips)
.088 ft
3
/cycle at 100 psi
Air consumption (2.5 ltr/cycle at 6.9 bar)
(2.5 ltr/cycle at 7 kgf/cm
2
)
Air inlet 3/8 NPT Thread
NAIL SELECTION
WARNING
Be sure to use only the genuine HITACHI nails for the NR83A2/NR83A2(S). The use of any other nails can result in
tool malfunction and/or nail breakdown, leading to serious injuries.
Only nails shown in the Table below can be driven with this Nailer.
ACCESSORIES
WARNING
Accessories other than those shown below can lead to malfunction and resulting injuries.
STANDARD ACCESSORIES
.113"
(2.9 mm)
.286"
(7 mm)
2" (50 mm)
.131"
(3.3 mm)
3-1/4" (83 mm)
Plastic-collated strip nails Min. Max.
Full-head nails
1 Eye protection 1
1
.3"
(7.6 mm)
